AIIS-DIO32 Startup Manual 1
Before you begin installing your card, please make sure that
the following items have been shipped:
1. 1 x AIIS-DIO module
2. 1 x Cable
3. 2 x Screws
4. 2 x POST (Silver color)
5. 2 x POST (Golden color; 18mm for AIIS-1240)
6. 2 x POST (Golden color; 20mm for AIIS-1440)
7. 1 x Startup manual
8. 1 x China RoHS
9. 1 x Warranty
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
AIIS-DIO32
DIO module, 32-bit, 9-pin USB interface
Startup Manual
General Features
• 16 isolated DI and 16 isolated DO channels
• High voltage isolation on all channels (2,500 V)
• Supports 5 ~ 60 Vdc isolated input channels
• Interrupt handling capability
• Timer/counter capability
Support List
AIIS-1240-00A1E
AIIS-1440-00A1E
Note: For more support list, please visit our website.
Mechanical and Environmental
• Dimensions: 95.9 mm x 46.2 mm
• Operating temperature: 0 ~ 45° C
• Operating humidity: 10 ~ 95% @40° C, Non-Condens-
ing
• Storage temperature: -40 ~ 70° C
• Storage humidity: 10 ~ 95% @60° C, Non-Condensing
• Weight: 0.3 kg
There is one connector on the module is used to connect
with AIIS Series Motherboard. The below table lists the
function of the connector.
Connectors
Label Function
USB1 Connecting module and MB
Specications
Packing List
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://support.advantech.com
This manual is for the IPMI-1000 Series.
Part No. 2006IO3200
Print in China
1st Edition
November 2013
Connector
