AIMC-3403 Startup Manual 1
Before you begin installing your cards and peripherals,
please make sure that the following items have been
shipped:
AIMC-3403 barebone system x 1
Startup manual for AIMC-3403 x 1 P/N: 2041340300
Startup manual for AIMB-505 x 1 P/N: 2006050510
Short mounting bracket x 2 P/N: 960062229N000
Long mounting bracket x 2 P/N: 960065577N000
M4 screws for mounting bracket x8
P/N: 1939000410
M3 screws for HDD x8 P/N: 1930000313
Rubber for HDD x8 P/N: 1990001365
Rubber for chassis stands p1-x4 PN: 1990032090S000
AIMC-3403 Front Access Micro Computer
Startup Manual
Processor System
Intel® 6th/7th generation Core™ i socket CPU
(LGA1151)
Memory
Supports dual channel 288-pin DDR4 2400MHz SDRAM.
16 GB per slot without ECC function; Max. capacity is
32GB
Graphics
Integrated Intel HD Graphics
Ethernet
Interface: 10/100/1000 Mbps
Controller: 2 x Realtek RTL8111G
Drive Bay
2 x 3.5” HDD, SATA 3.0
1 x mSATA
Front I/O
Display:
- 1 VGA, Max. resolution 1920x1200 @ 60Hz
- 1 DVI-D, Max. resolution 1920x1200 @ 60Hz
- 1 DP, Max. resolution 4096x2304 @ 60Hz
- Supports dual display (DP+DVI-D, DP+VGA or DVI-
D+VGA)
USB: 4 USB3.0, 4 USB2.0
Serial: 2 x RS-232/422/485, 8x RS -232
5HPRWH6ZLWFKRQRႇ 2-pin terminal block
Audio: Line-out/Mic-in
Expansion Slots
1z PCIe x16 (Gen.3), 2 x PCIe p1-x1 (Gen.2), 1 x PCI,
1 x Full-Size mini-PCIe (supports mSATA)
Power Supply
Output rating: AC 250W ATX PSU embedded
Input Voltage: 100 VAC ~ 240 VAC
Miscellaneous
LED Indicators: Power, HDD
Control: 3RZHURQRႇVZLWFKUHVHWEXWWRQ
Environments
Operating Temperature: 0 ~ 40 °C (32 ~ 104 °F)
Storage Temperature: -20 ~ 60 °C (-4 ~ 140 °F)
Relative Humidity: 95% @ 40° C (non-condensing)
Physical Characteristics
Dimensions (WxHxD): 330 x 148 x 300 mm
Weight: 6.3 kg (13.89 lbs)
Packing List
For more information on this and other Advantech
products,
please visit our website at:
http://www.advantech.com
For technical support and service, please visit our
support website for AIMC-3403 at:
http://advt.ch/AIMC3403
Part No. 2041340300 1st Edition
Printed in China July 2020
