MIO-2364 Startup Manual 1
Before you begin installing your card, please make sure that
the following items have been shipped:
1. 1 x MIO-2364 SBC
2. 1 x Startup Manual P/N: 2046236400
3. 1 x SATA Cable P/N: 1700006291
4. 1 x Audio Cable P/N: 1700019584-01
5. 2 x COM Cable P/N: 1700030404-01
6. 1 x USB 2.0 Cable P/N: 1700030406-01
7. 1 x SATA Power Cable P/N: 1700027546-01
8. 1 x AT Power Cable P/N: 1700019705-01
9. 1 x Cooler for 15W CPU P/N: 1970005708T001
10. 1 x Heatsink for 12/6W CPU P/N: 1970005779T001
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note 1: For detailed contents of MIO-5154, please refer
to the Advantech website for detailed informa-
tion.
Note 2: AcrobatReaderisrequiredtoviewanyPDFle.
Acrobat Reader can be downloaded at: http://
get.adobe.com/reader (Acrobat is a trademark of
Adobe).
Intel® Core™ i3-N305, Intel® N-Series, and Intel®
Atom® x7000E Series Processor Pico-ITX SBC
(Code name: Alder Lake N)
Startup Manual
General
• CPU:
- Intel® Core™ i3-N305 Processor, 8 cores
- Max Frequency 3.8GHz
- Intel® N-Series Processor N97, 4 cores
- Max Frequency 3.6GHz
- Intel® x7000E Series Processor x7211E, 2 cores
- Max Frequency 3.2GHz
• System Memory: Single Channel, SODIMM DDR5-4800
MT/s, up to 16GB
• CPU TDP:
- Core™ i3-N305: 15W
- N-Series N97: 12W
- x7000E Series x7211E: 6W
• BIOS: AMI uEFI 256 Mbit
• Watchdog Timer: 0~6553 sec
• Battery: Lithium 3 V/210 mAH
• Audio: High-denitionaudio(HD),Line-in,Line-out,
Mic-in
Expansion Interface
• 1 x M.2 E-Key 2230
• 1 x M.2 B-Key 2242/3042/3052
Display
• Controller: Intel® UHD Graphics (SoC integrated)
• Maximum Resolution:
- LCD:
LVDS dual channel 12-/24-bit up to 1920 x 1200
- HDMI:
HDMI 1.4b, up to 3840 x 2160 x 24bpp@20-30Hz
• Multiple Displays:
Dual Simultaneous Display: LVDS + HDMI
Ethernet Interface
• Speed: 10/100/1000/2500 Mbps
• Controller: 1x Intel® i226LM
Mechanical and Environmental
• Dimensions: 100x72mm(3.9″x2.8″)
• Power Supply Type: ACPI support
• Power Requirement: +12 V ± 10% (Default supports
ATX 2x2-pin 90D, DC Jack by T-P/N)
• Operating Temperature:
0 ~ 60°C (32 ~ 140°F)
Specications Packing List
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://advantech.com/support
This manual is for the MIO-2364.
Part No. 2046236400
Printed in China
1st Edition
February 2024
