PCM-37D24DI Startup Manual 1
Before installation, please ensure that the following items
have been included in your shipment:
1. 1 x M.2 card with controller
2. 1 x DB37 I/O plate x 1 with iDoor bracket
3. 1 x Wired cable
4. 1 x Extension bracket kit
5. 1 x Startup manual
6. 1 x Warranty card
If any of the above items are missing or damaged, contact
your distributor or sales representative immediately.
The support documentation and drivers can be accessed
from Advantech website.
• Documentation
- Datasheet
- StartUp
• Drivers
PCM-37D24DI
24-Channel Isolated Digital I/O, M.2 B+M key
(3042, PCIe*1), DB37
Startup Manual
The following table and fi gure show the pin assignments of
the connector on the bracket of the I/O module.
Description of PIN Use
IDIn (n=0 ~ 15) Isolated digital input
IDOn (n=0 ~ 7) Isolated digital output
ECOM0 External common of IDI0~7
ECOM1 External common of IDI8~15
PCOM
Free wheeling common diode
for IDO
EGND External ground
NC Not Connected
Packing List
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
For technical support services, please visit our support
website at:
http://www.advantech.com.tw
This manual is for PCM-37D24DI.
Part No. 204137D200
Printed in Taiwan
Edition 1
December 2024
