UNO-2271G V2 Startup Manual 1
Before you begin installing your card, please make sure that
the following items have been shipped:
1. UNO-2271G V2
2. 2-pin Plug-in block for power wiring
3. Startup Manual
4. China RoHs sheet
5. Warranty card
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note: Acrobat Reader is required to view any PDF
le. Acrobat Reader can be downloaded at: get.
adobe.com/reader (Acrobat is a trademark of
Adobe)
Caution: DANGER OF EXPLOSION IF BATTERY IS
INCORRECTLY REPLACED. REPLACE ONLY
WITH THE SAME OR EQUIVALENT TYPE
RECOMMENDED BY THE MANUFACTURER,
DISCARD USED BATTERIES ACCORDING TO
THE MANUFACTURER’S INSTRUCTIONS.
UNO-2271G V2 Pocket-Size Edge IoT Gateway
with Intel® Celeron® N6210/ Pentium® N6415
Startup Manual
Attention: DANGER D’EXPLOSION SI LA BATTERIE EST
INEXACTEMENT REMPLACÉE. REMPLACEZ
SEULEMENT AVEC LA MÊME CHOSE OU
LE TYPE ÉQUIVALENT RECOMMANDÉ PAR
LE FABRICANT, JETTENT LES BATTERIES
UTILISÉES INSTRUCTIONS DE S SELON
FABRICANT DES’.
Specications
Processor System
• Intel Celeron® N6210 1.2GHz
• Intel Pentium® N6415 1.2GHz
Memory
• Onboard 4GB DDR4 1600MHz (Up to 8GB)
Graphics
• Intel® UHD Graphics
Ethernet
• 2 x Intel® I210-AT, IEEE1588
Storage
• Onboard 32/64GB eMMC (upgradeable, up to 256GB)
• Option mSATA shared with mPCIe slot
Expansion
• 1 x Full-size mPCIe (SATA/PCIe/USB2.0 signal)
• 1 x Nano SIM card slot
External I/O
• Display: 1 x HDMI (1920 x 1080 @60Hz)
• USB: 2 x USB 3.2 GEN1
Power Requirements
• Power type: AT
• Power Input Voltage: 10 ~ 30 V
DC
• Power Connector: 1 x 2-pin terminal block
This product is intended to be supplied by a UL certied
power supply or UL certied DC source rated 10Vdc, 7.7A
minimum, Tma 40°C minimum, if you need further assis-
tance, please contact Advantech for further information.
Environment
• Operation Temperature: -20°C~60°C (-4°F ~140°F with
0.7 m/s airow)
• Storage Temperature: -40°C ~ 85°C (-40°F ~ 185°F)
• Relative Humidity: 95% RH @ 40°C/104°F, non-
condensin
Physical Characteristics
• Dimensions (W x H x D): 100 x 70 x 30 mm
(3.9 x 2.8 x 1.2 in)
• Weight: 0.5 kg (1.1 lb)
Packing List
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
For technical support and service, please visit our sup-
port website for UNO-2271 V2 at:
Register your products on our website and get 2
months extra warranty for Free at:
http://www.register.advantech.com
Part No. 2041227120 1st Edition
March 2025
Packing List (Cont.)
