OWNER’S MANUAL
AMP1200VS
AudioSource®
13970 SW 72nd Ave
Portland, OR 97223
503.914.4688
www.audiosource.net
AMP1200VS Owner’s Manual 72015
Congratulations on your purchase of the AudioSource® AMP1200VS.
Please take a few moments to read this entire manual, and be sure to
retain this document for future reference. Please read and observe all
safety instructions detailed on page 2.
NOTE: If any part of this product is damaged or missing, please call your
dealer or AudioSource® directly at 1.877.715.5439 or 503.914.4688.
Please read your warranty and retain your receipt and original carton
for possible future use.
For more information about AudioSource® electronics, speakers and
accessories please visit www.audiosource.net
FEATURES:
SPECIFICATIONS
Stereo (8 ohm): 12 x 40W per channel, <0.2% THD+N
Stereo (4 ohm): 12 x 40W per channel, <0.2% THD+N
Bridged Mono (8 ohm): 80W, 1kHz, <0.2% THD+N
Frequency Response: 10Hz ~ 50kHz, +0dB/ -3dB
Signal to Noise Ratio:
100dB below 150W output into 8 ohms
Channel Separation: 70dB @ 1kHz, referred to 150W output
into 8 ohms
Input Sensitivity: Variable, 350mV to 2.8V for rated power
into 8 ohms
AC Power Consumption: 1000W maximum
Net Weight: 30lbs / 13.6kgs
Gross Weight: 36lbs / 16.3kgs
Multi-Zone Power Amplifier
AMP1200VS
12 Independent Channel inputs, 2 Buss Inputs
2 Buss Outputs
Independent Channel Gain Controls
Manual, Auto, or Triggered On/Off Modes
Bridgeable Channel Outputs
Rack Mountable (Rack Mount Included)
LED Status Indicator Lights
Phoenix-Style Speaker Connectors
Stable Class A/B Design
Extensive Protection Circuitry
4.0”
(102mm)
16.5” (419mm)
14.25”
(361mm)
MULTI-ZONE POWER AMPLIFIER
AMP1200VS
