AXLOCM-150 AXLOCM-150
INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS
AXLOCM-150 AXLOC M-150
INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS
REV. 12/13/19 REV. 12/13/19© COPYRIGHT 2019 METRA ELECTRONICS CORPORATION © COPYRIGHT 2019 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com Integrate • AxxessInterfaces.com
REV. 12/13/19 REV. 12/13/19© COPYRIGHT 2019 METRA ELECTRONICS CORPORATION © COPYRIGHT 2019 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com Integrate • AxxessInterfaces.com
The Line Output Converter (LOC) should be installed on a stereo’s speaker output wires or the output
wires on an OEM amplifier of up to 75 watts per channel. These wires can be found behind the stereo
in the dash, on the outside of an OEM amplifier, or on the input terminals on the OEM speakers.
Wire color and function
The audio input wire colors are an EIA standard for car stereo applications as follows:
Yellow Battery +12v input
Black Ground input
Blue Remote +12v output the above power wires can be connected directly
to the amplifier being added
White Left front (+) input
White/Black Left front (-) input
Gray Right front (+) input
Gray/Black Right front (-) input
Black/White Reference ground (-) (reference ground optional if noise is present)
Note: Be sure that all audio input connections are polarized or in phase with each other. That is, the
positive output wires from the audio source need to be connected to the corresponding positive
input wires of the LOC. The same goes for the negative audio wires. Failure to do this will result in
poor bass response and low quality audio.
Continued on other side
The Line Output Converter (LOC) should be installed on a stereo’s speaker output wires or the output
wires on an OEM amplifier of up to 75 watts per channel. These wires can be found behind the stereo
in the dash, on the outside of an OEM amplifier, or on the input terminals on the OEM speakers.
Wire color and function
The audio input wire colors are an EIA standard for car stereo applications as follows:
Yellow Battery +12v input
Black Ground input
Blue Remote +12v output the above power wires can be connected directly
to the amplifier being added
White Left front (+) input
White/Black Left front (-) input
Gray Right front (+) input
Gray/Black Right front (-) input
Black/White Reference ground (-) (reference ground optional if noise is present)
Note: Be sure that all audio input connections are polarized or in phase with each other. That is, the
positive output wires from the audio source need to be connected to the corresponding positive
input wires of the LOC. The same goes for the negative audio wires. Failure to do this will result in
poor bass response and low quality audio.
Continued on other side
The Line Output Converter (LOC) should be installed on a stereo’s speaker output wires or the output
wires on an OEM amplifier of up to 75 watts per channel. These wires can be found behind the stereo
in the dash, on the outside of an OEM amplifier, or on the input terminals on the OEM speakers.
Wire color and function
The audio input wire colors are an EIA standard for car stereo applications as follows:
Yellow Battery +12v input
Black Ground input
Blue Remote +12v output the above power wires can be connected directly
to the amplifier being added
White Left front (+) input
White/Black Left front (-) input
Gray Right front (+) input
Gray/Black Right front (-) input
Black/White Reference ground (-) (reference ground optional if noise is present)
Note: Be sure that all audio input connections are polarized or in phase with each other. That is, the
positive output wires from the audio source need to be connected to the corresponding positive
input wires of the LOC. The same goes for the negative audio wires. Failure to do this will result in
poor bass response and low quality audio.
Continued on other side
The Line Output Converter (LOC) should be installed on a stereo’s speaker output wires or the output
wires on an OEM amplifier of up to 75 watts per channel. These wires can be found behind the stereo
in the dash, on the outside of an OEM amplifier, or on the input terminals on the OEM speakers.
Wire color and function
The audio input wire colors are an EIA standard for car stereo applications as follows:
Yellow Battery +12v input
Black Ground input
Blue Remote +12v output the above power wires can be connected directly
to the amplifier being added
White Left front (+) input
White/Black Left front (-) input
Gray Right front (+) input
Gray/Black Right front (-) input
Black/White Reference ground (-) (reference ground optional if noise is present)
Note: Be sure that all audio input connections are polarized or in phase with each other. That is, the
positive output wires from the audio source need to be connected to the corresponding positive
input wires of the LOC. The same goes for the negative audio wires. Failure to do this will result in
poor bass response and low quality audio.
Continued on other side
2 Channel Line Output Converter (LOC) with Amp Turn-On
2 Channel Line Output Converter (LOC) with Amp Turn-On
2 Channel Line Output Converter (LOC) with Amp Turn-On
2 Channel Line Output Converter (LOC) with Amp Turn-On
