CMX44AB USER MANUAL
01
contact support@blustream.co.uk / support@blustream.com.au
User Manual
CMX44AB
Our Contractor CMX44AB 4K HDMI matrix features HDMI 2.0 chipsets with HDCP 2.2 support, allowing
distribution of four HDMI sources to four displays. This enables all sources to be viewed seamlessly as
required within a matrix configuration. The unit transmits all HDMI resolutions up to and including 4K 60Hz
4:4:4/HDR. The 4-Way matrix also includes audio breakout and EDID management.
Introduction
Key Features:
• Features 4x HDMI inputs which can be independently routed to 4x HDMI outputs
• Supports 4K UHD video (up to 4K @60Hz 4:4:4/HDR)
• Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
• Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and
DTS-HD Master Audio transmission
• HDMI audio breakout to associated output analogue L/R audio and coaxial digital outputs concurrently
• Control via front panel, IR and RS-232
• IR routing
• Supplied with Blustream 5V IR receivers and emitters
• 3rd Party drivers available for all major home control brands
• Advanced EDID management
• HDCP 2.2 compliant
.
DC 12V
IR Ext
On/Off
3 2 1
1
0
0
EDID
CMX44AB
IR Input
Coaxial
Output 1 Output 2 Output 3 Output 4
L/R
Input Output
IR Output
HDMI 1 HDMI 2 HDMI 3 HDMI 4 HDMI 1 HDMI 2 HDMI 3 HDMI 4
Coaxial L/R Coaxial L/R Coaxial L/R
IR
1
1
1
1
2
2
2
2
3
3
3
3
4
4
4
4
Power
4x4 4K HDMI 2.0 Matrix
.
DC 12V
IR Ext
On/Off
3 2 1
1
0
0
EDID
CMX44AB
IR Input
Coaxial
Output 1 Output 2 Output 3 Output 4
L/R
Input Output
IR Output
HDMI 1 HDMI 2 HDMI 3 HDMI 4 HDMI 1 HDMI 2 HDMI 3 HDMI 4
Coaxial L/R Coaxial L/R Coaxial L/R
IR
1
1
1
1
2
2
2
2
3
3
3
3
4
4
4
4
Power
4x4 4K HDMI 2.0 Matrix
