HD 2D1 B
Do Mixi DAC 2-Way I itter & Sca rwn ng HDM Spl le
Key Features
•
Features an in-built DAC (Digital to Analogue audio Converter) that
converts 5.1ch Dolby Audio or DTS Audio to a stereo 2ch signal
available on HDMI, optical and analogue audio outputs concurrently
• Supports the following audio input formats: Dolby 5.1, DTS-ES 6.1,
DD+5.1, DD+2.0, PCM 5.1, PCM 2.0*
• Features 1 x HDMI input supporting 4K UHD video (4K 60Hz 4:4:4) that
is replicated to 2 x HDMI outputs
• HDMI loop out will replicate the HDMI input signal up to 4K 60Hz 4:4:4
and 5.1 Dolby Audio & DTS Audio
• HDMI output 2 features a video scaler allowing the output resolution to
be set to the following formats:
- 3840x2160@60Hz
- 3840x2160@50Hz
- 3840x2160@30Hz
- 3840x2160@25Hz
- 4K DCI@25Hz 4:4:4
- 4K DCI@30Hz 4:4:4
- 4K DCI@50Hz 4:4:4
- 4K DCI@60Hz 4:4:4
- 1920x1080@60Hz
- 1920x1080@50Hz
- 1280x720@60Hz
- 1280x720@50Hz
- 1920x1200@60Hz
- 1680x1050@60Hz
- 1024x768@60Hz
• HDMI audio breakout to downmixed analogue L/R audio and
downmixed optical digital outputs concurrently
• HDCP 2.2 compliant with advanced EDID management
* This product does not support decoding of DTS CD bitstreams
•
Video Input Connectors: 1 x HDMI Type A, 19-pin, female
• Video Output Connectors: 2 x HDMI Type A, 19-pin, female
• Audio Output Connectors: 1 x Optical (Toslink), 2 x RCA analogue left
/ right
• EDID: 4-PIN DIP switch
• Resolution: 4-PIN DIP switch
• Product Upgrade: 2 x Micro USB female
• Dimensions (W x H x D): 127mm x 23mm x 104mm, without feet
• Shipping Weight: 1.0kg
• Operating Temperature: 32°F to 104°F (0°C to 40°C)
• Storage Temperature: -4°F to 140°F (-20°C to 60°C)
• Power Supply: 5V/3A DC
w w w . b l r . c o . u ku s t e a m
w w w r e a c o u. b l u s t m . m . a
Description
The ustream H has g to convert and do m em ed Bl D12DB been desi ned wn ix bedd
5.1 ol dio DMI al 2chch D by Au or DTS Audio within a H gnsi into a stereo signal
avai on H l ue io ou ts. The H fea res a lable DMI, optica and analog aud tpu D12DB tu
H I lo out to pa the origi l vi o DM op ss na de and mu ti hannl -c el em d d aud be de io sig l na
to compatible equipment, w h a second HDMI output featuring video s ling of up it ca
to 4K 60Hz 4:4:4 video to various lower resolution video formats. This provides the
audio can be distributed around a multi-room system where there are a mixture of
2ch and 5.1ch zones with multiple output resolution requirements.
Regulatory Compliance
CAN ICES-3 (B)/NMB-3(B)
Included A essories cc
Rack Mount 1 x Mounting Kit
Power Supply 5V/3A DC PSU
23mm
127mm
