Engineered Solutions | Contactless MIFARE Identification Cards
Contactless MIFARE Identification Cards
www.boschsecurity.com
uPVC plastic card
uCredit card size
uImprinted card number
uMIFARE Classic chip or
MIFARE DESFire EV1 chip
The proximity cards are contactless credential and
available with either MIFARE classic or MIFARE
DESFire EV1 chip. They include an imbedded antenna
and an integrated circuit, enabling contactless reading
with the respective readers. The unique badge number
is printed on top of the card enabling contactless
reading by readers.
The credit card sized card conforms to the ISO-
standard size enabling surface printing with
conventional ISO compatible card printers. This card is
durable with IP 68 and can be fully submerged, all the
electronics are sealed inside.
Functions
• MIFARE cards have a wire antenna and a MIFARE Chip
embedded.
• The card is recognized and read when held in front of
the reader.
• The reading process is passive with a frequency of
13.56 MHz.
• MIFARE cards support multiple application areas that
can be individually protected.
Certifications and approvals
ISO/14443 Typ A
Installation/configuration notes
Contactless credentials with Mifare chip are ideal for
installations with high-availability systems and where
credentials may be exposed to abnormal conditions
Technical specifications
ACD-MIFARE card
Dimensions 85.7 x 54 x 0.76 mm
Chip Write Endurance 100,000
Coding Card number (unique)
System Bosch ST Coding
• Chip number (unique)
• Customer code 9000
• Country code 0
• Version 0
Transmission frequency 13.56 MHz
Data preservation 10 years
Transaction times < 100 ms
