Intrusion Alarm Systems | B299 Expansion module, SDI2
B299 Expansion module, SDI2
www.boschsecurity.com
uProvides point identification for up to 100
connected addressable initiating devices using
POPITs
uSupervises wiring to devices for circuit integrity
uExpands the number of points in the system
uCompact size
uInterconnect wiring connectors for easy installation
The B299 POPEX Module is an SDI2 compatible
device. The module communicates to the control panel
over the SDI2 bus, and provides support for up to 100
POPIT (Point Of Protection Input Transponder)
devices. This occurs over a single expansion loop using
two pairs of terminals.
System overview
Each module installs in the control panel enclosure or
in an adjacent approved enclosure. Future system
expansion is very economical as the module supports
zone expansion through supporting D9127U/T POPIT
modules and POPIT’ed detectors. The POPIT modules
can be placed anywhere along the two-wire data
expansion loop from the module.
Certifications and approvals
Region Regulatory compliance/quality marks
USA ANSI-
SIA
CP-01-2010-Control Panel Standard -
Features for False Alarm Reduction
UL Underwriters Laboratories
UL UL 1023 - Household Burglar Alarm Sys-
tem Units
UL UL 1076 - Proprietary Burglar Alarm
Units and Systems
Region Regulatory compliance/quality marks
UL UL 1610 - Central Station Burglar Alarm
Units
UL UL 1635 - Standard for Digital Alarm
Communicator System Units
UL UL 294 - Standard for Access Control
Units and Systems
UL UL 365 - Police Station Connected Bur-
glar Alarm Units
UL UL 609 - Standard for Local Burglar
Alarm Units and Systems
UL UL 636 - Holdup Alarm Units and Sys-
tems
UL UL 864 - Standard for Control Units and
Accessories for Fire Alarm Systems
(10th edition)
UL UL 985 - Household Fire Warning Sys-
tem Units (6th edition)
FM Central Station
FM Local Protective Signaling
FM Remote Station
CSFM California Office of The State Fire Mar-
shall
FCC Part 15 Class B
Probleemoplossing Bosch B299
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Gewicht: | 300 g |
| Breedte: | 73.5 mm |
| Diepte: | 127 mm |
| Hoogte: | 15.25 mm |
| Connectiviteitstechnologie: | Bedraad |
| Type stroombron: | DC |
| Kleur behuizing: | Zwart |
| Ingangsspanning: | 12 V |
