Integrated LCD Systems
ENGLISH
Integrated LCD System
BASIC OPERATION GUIDE
ENGLISH 4
DT Research, Inc.
2000 Concourse Drive, San Jose, CA 95131 h p://www.dtresearch.com
Copyright © 2013, DT Research, Inc. All Rights Reserved. DT Research is a registered trademark of DT Research, Inc.
INTRODUCTION
Thank you for acquiring the DT Research Integrated LCD System, a 15-inch/ 17-inch/ 19-inch/ 21.5-
inch/ 24-inch TFT display-integrated, thin compu ng pla orm, offering adaptability to moun ng
con gura ons and applica ons, including informa on appliance, thin client for server compu ng, fi
and disk drive-equipped op ons.
Please take a few moments to review the contents of this document to ensure that the setup and
startup proceed smoothly. The DT Research Integrated LCD System is ready for use, out of the box,
in its default con gura on when powered by the power source provided. The following discussion fi
o ers guidance on the hardware elements and features of the DT Research Integrated LCD System. ff
Please refer to your device provider for informa on pertaining to the so ware opera ng system or
so ware applica ons.
Package Contents
O• ne DT Research Integrated LCD System with desktop stand
A
• C/DC power adapter with power cord
B• asic opera on guide
Precau ons
Always exercise care when opera ng and handling the DT Research Integrated LCD System.•
Never disassemble any por on of the enclosure, as this will void any product warranty on the •
DT Research Integrated LCD System.
Do not use any AC/DC adapter other than the one provided with the device or a replacement •
acquired from the manufacturer.
I• n the unlikely event that smoke, abnormal noise, or strange odor is present, immediately power
down the DT Research Integrated LCD System and disconnect all power sources. Please report
the problem to your device provider immediately.
BOG031913ILENG
Moun ng
The DT Research Integrated LCD System is designed to be secured to VESA-compliant mounng
arms or stands. This is accomplished by equiping the standard metal base on the rear of the display
unit. The VESA-compliant moun ng holes at the rear of the device will mate with VESA mounts or
arms to meet the requirements of the deployment.
Remove the detachable base by pressing 1.
upward to remove the cover, then unscrewing
the four screws a aching the base to the
display.
Aach the new VESA-compliant moun ng 3.
device or stand to the display.
The display without the base.2.
The display successfully mounted on a 4.
VESA-compliant moun ng arm.
Probleemoplossing Chief MFMUS
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Zilver |
| Breedte: | 917 mm |
| Diepte: | 640 mm |
| Hoogte: | 1394 mm |
| Soort: | Multimediawagentje |
| Maximale gewichtscapaciteit: | 56.7 kg |
| Materiaal: | Metaal |
| Paneelmontage-interface: | 100 x 100 mm |
| Aanbevolen gebruik: | Vlakke paneel |
| Maximale schermgrootte: | 55 " |
| Minimale schermgrootte: | 30 " |
