Chief
Flat panel steun
PLP2000B
Chief PLP2000B Handleiding
Hier is de Chief PLP2000B (Flat panel steun) gebruikershandleiding. 8 pagina's in taal Engels met een gewicht van 1.8 Mb. Als u geen antwoorden op uw probleem kunt vinden Vraag het onze community.
Pagina 1/8
CHIEF MANUFACTURING INC. 8805-000183 Rev F
1-800-582-6480 952-894-6280 FAX 952-894-6918 ©2008 Chief Manufacturing
8401 EAGLE CREEK PARKWAY, STE. 700 www.chiefmfg.com
SAVAGE, MINNESOTA 55378 USA 03/08
I N S T A LL A T I O N IN S T R U C T IO N S
PLP Series Wall Mount
The PLP Series wall mount accommodates large flat
screens weighing up to 200 lbs (90.72kg). The teardrop
holes in the mount allow for quick connect/disconnect of
the screen, thus simplifying installation and maintenance
processes.
The top and bottom mounting brackets are adaptable to
supporting framework with wood studs that are 16” on
center or 24”on center.
The mount has integrated lateral shift, allowing for four
different mounting options. For dual wood studs 16” on
center, the lateral shift is + 4.5 inches. For dual wood
studs 24” on center, the lateral shift is + 0.5 inches.
The display can be pulled and tilted by hand into any
position in the zero-to-15 degree tilt range and remain
stationary.
The bottom of the mount pulls forward 4” from the wall
and locks into place for installation of cable connections.
The mount also uses Chief’s exclusive Q-Latch™
mounting system, which offers quick connect/disconnect
display mounting. The display is secured to the mount
with a latching flag. For additional security, you can lock
the latching flag in place by adding a padlock. PLP Series
Probleemoplossing Chief PLP2000B
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Zwart |
| Breedte: | 660 mm |
| Diepte: | 46.5 mm |
| Hoogte: | 467 mm |
| Materiaal behuizing: | Staal |
| Montagewijze: | Muur |
| Maximale gewichtscapaciteit: | 90.7 kg |
| Certificering: | TUV Approved, UL Listed |
| Paneelmontage-interface: | - mm |
| Bereik kantelhoek: | 0 - 15 ° |
| Maximale schermgrootte: | 71 " |
| Minimale schermgrootte: | 42 " |
| Afstand tot de muur (min): | 46.5 mm |
