Project
Item
Quantity
FCSI Section 11400
Approved
Date
760 Beta Drive, Unit D
Mayeld Village, Ohio 44143
Tel 1.216.481.4900
Fax 1.216.481.3782
Email steam@clevelandrange.com
www.clevelandrange.com
Timeless Quality, Trusted For Life ®
Mixer Kettles
Standard Features
• Solid State Temperature Control (±1°F) for perfect simmering
• Solid State Low Water Safety Control
• Steam jacket filled with treated water, venting and/or refilling is
not required
• 50 psi Safety Valve and Steam Jacket Rating
• No Water Gauge required
• Rear mounted Pressure/Vacuum Gauge and Pressure Relief Valve
• Infinitely variable Scraper Speed Control from 0-40 rpm
• Infinitely Variable Ratio between Scraper And Agitator: Agitator
rotates from 0-8 times the speed of the Scraper
• Removable (without tools) Nylon Blades scape entire Jacketed
surface
• 3 Horsepower Hydraulic powered Agitator, Scraper and Bridge Lift
• Safety device prevents high speed starts
• Mixing stops when bridge is lifted - includes safety cover and
screen
• Agitator and Scraper are bayonet mounted for easy removal
• Tilt mechanism of Roller Bearings and case hardened Self-Locking
worm and segment gear
• Hot and Cold Water Faucets
• 2" diameter Tangent Draw-Off Valve with Drain Strainer
• All Plumbing , Electrical and Hydraulics enclosed in Stainless Steel
Consoles
• Enclosed, 10 Gauge Stainless Steel hydraulically operated Mixer
Bridge
• Kettle and all exterior surfaces are Stainless Steel
• Level adjustable feet (flanged for bolting)
• Large Pouring Lip
• Gallon Markings stamped into Scraper Shaft
• Standard 208-240 volts, 60 Hz, 3 phase, 4 wire, high wattage
• Typical approvals include UL., CSA, CE, NSF and ASME
• 316 Stainless Steel Interior
• Two piece cover with safety screen
Options & Accessories
• Easydial style controls with Time, Temperature and Probe
Temperature Control with Data Logger (EZDYCICL)
• Food Strainer (FS-20)
• Flow Diverter (FD)
• Pan Carrier (PCK)
• Swing Funnels (SF-1 or SF-2)
• Power Tilt (PT)
• Kettle Accessory Kit (KAK) includes:
• Clean-up Brush (CB) • 36˝ Kettle Paddle (KP)
• 36˝ Kettle Whip (KW) • 36˝ Kettle Brush (KB)
• Draw-off Brush (DB) • 24 oz. Ladle (KL)
• Water Meter (GMF or LMF) Wall Mount or on Stand (SWM)
• Leg Extensions
• Voltages (VOS) other than standard
• Temperature Chart Recorder (TCR)
Short Form Specifications
Shall be CLEVELAND, Model MKEL- _____ -T,
console/Leg mounted, Electric Mixer Kettle with
permanently filled Steam Jacket; 50 psi Kettle
Jacket Rating and Safety Valve, High Wattage
standard, Solid State Temperature (±1°F) and
Low Water Safety Controls. 3 H.P. Hydraulic
powered Scraper/Agitator and Bridge Lift. 0-40
rpm Scraper Speed with Variable Scraper to
Agitator Ratio from 1-1 to 8-1.
Type 316 Stainless
Steel interior
, Stainless Steel enclosed Mixer
Bridge. All Plumbing, Electrical and Hydraulics
enclosed in Consoles. Gallon Markings. Safety
Device prevents high speed starts. Safety Device
prevents high speed starts; Mixer stops when
Bridge is lifted. Bayonet Mounted Agitator and
Scraper. 2" Tangent Draw-0ff Valve. Hot and Cold
Water Faucet. Kettle and all exterior surfaces are
Stainless Steel. 316 Stainless Steel Interior.
MIXER KETTLE, ELECTRIC
LEG MOUNTED, CONSOLE TYPE
2/3 JACKETED, TILTING
Shown with optional Power Tilt
& Product Temperature Control
KE004046-80
Section 8, Page 5
5663A 11 / 2023
Models
• MKEL-40-T • MKEL-80-T
• MKEL-60-T • MKEL-100-T
