Pagina 1/2
4 Direct Contact heatpipes for seamless contact
between cooler and CPU.
120mm wide range PWM fan, RPM can be fine tuned
for maximum airflow or whisper quiet operation.
Snap-On fan brackets to quickly and easily install,
remove, clean or replace the fan or heatsink.
Versatile all- -one mounting solution supporting the in
Intel® LGA 2011/13 1156/1155/775 and AMD 66/
FM2+/FM2/FM1/AM3+/AM3 /AM2
The Cooler Master Hyper T4 is an affordable
mainstream Heatsink delivering great cooling
performance on all modern platforms thanks to its 4
specially shaped direct touch Heatpipes. The T4’s
120mm PWM fan features a wide fan speed range and
can be fine tuned for maximum airflow and cooling
performance or silent operation. Thanks to this
flexibility, a quick and easy snap-on fan bracket and a
universal mounting system the Hyper T4 is a great
match for any system.
CPU Socket
Intel®
LGA 2011/1366/1156/1155/1150/775
AMD FM2+/FM2/FM1/AM3+/AM3 /AM2
Dimensions
131.6 x 72.5 x 152.3 mm (5.2 x 2.9 x 6 in)
Heat Sink Dimensions
128 152.3 mm (5 1.7 6 x 44 x x x in)
Heat Sink Material
4 Direct Contact Heatpipes / Aluminum Fins
Heat Sink Weight
4 g 1 48 / lb
Heat Pipe Dimensions
Ø 6mm
Fan Dimensions
120 120 x 25 mm (4.7 4.7 x 1 in) x x
Fan Speed
600~1800 RPM (PWM) ± 10%
Fan Air Flow
24~70 CFM ± 10%
Fan Air Pressure
0.3~ mm H2.14 2O ± 10%
Fan Life Expectancy
40,000 hours
Noise Level
15.1~31.6 dBA
Bearing Type
Rifle bearing
Connector
4- Pin
Rated Voltage
12 VDC
Rated Current
0.2A**
Power Consumption
2.64 W
Fan Weight
100 g / 0.22 lb
Net Weight
650 g / 1.43 lb
Gross Weight
804 g / 1.77 lb
EAN Code
4719512038826
UPC Code
884102018206
Package Dimensions
1 5 1 63 x 11 x 85 mm
(6.4 4.5 7.3 x x in)
Carton Dimensions
506 246 392 x x mm
(19.9 9.7 15.4 x x in)
Unit / Carton
12
Carton / Pallet
40
Hyper T4
RR-T4-18PK-R1
2 years
Features
Specifications
Package Information
Warranty
Probleemoplossing CoolerMaster Hyper T4
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Black, Metallic |
| Gewicht: | 548 g |
| Breedte: | 131.6 mm |
| Diepte: | 72.5 mm |
| Hoogte: | 152.3 mm |
| Soort: | Koeler |
| Geluidsniveau (hoge snelheid: | 31.6 dB |
| Materiaal: | Aluminium |
| Minimum luchtstroom: | 24 cfm |
| Maximum luchtstroom: | 70 cfm |
| Aantal ventilatoren: | 1 ventilator(en) |
| Spanning: | 12 V |
| Rotatiesnelheid ( max): | 1800 RPM |
| Mean time between failures (MTBF): | 40000 uur |
| Aansluiting(en): | 4-pin PWM |
| Rotatiesnelheid ( min): | 600 RPM |
| Geschikte locatie: | Processor |
| Compatibele processors: | Niet ondersteund |
| Stroomverbruik (typisch): | 2.64 W |
| Ventilator diameter: | 120 mm |
| Nominale netspanning: | 0.2 A |
| Bearing technologie: | Gegroefd |
| Supported processor sockets: | Socket AM2, Socket AM3, Socket AM3+, Socket FM1 |
| Maximum luchtdruk: | 2.14 mmH2O |
| Heatsink afmetingen (B x D x H): | 128 x 44 x 152.3 mm |
| Minimum luchtdruk: | 0.3 mmH2O |
