CoolerMaster k550 Handleiding
Hier is de CoolerMaster k550 (Computerbehuizing) gebruikershandleiding. 2 pagina's in taal Engels met een gewicht van 1.2 Mb. Als u geen antwoorden op uw probleem kunt vinden Vraag het onze community.
Pagina 1/2
Armor-inspired front mesh panel
Large windowed side panel with fan mounting allows
users to install two optional 120mm fans
Ultra-strong top carrying handle with rubber coating
One USB 3.0 super speed port for 10x faster file
transfer and smart phone / tablet charging (~1A)
Supports up to 7 fans, including one pre-installed
120mm red LED fan in the front
Removable HDD cage allows easy cable management
Supports high-end graphics cards up to
363mm/14.3 in length, including NVIDIA GTX 690 ”
and AMD HD 7990 after removing the 1st HDD cage
K550 is a mid-tower for general users in emerging markets. One
pre-installed, 120mm, red LED fan is included behind the
armor-inspired front panel. It supports up to 7 HDD bays for plenty of
expansion and cable management High-end graphics cards, like .
NVIDIA GTX690 and AMD HD 7990, can fit inside after removing the
1st HDD cage. Up to seven fans are supported, including two on the
windowed side panel to keep graphic cards cool. Additionally, the USB
3.0 port has 10x faster file transfer and 2x faster phone/tablet
charging than USB 2.0.
Available Color
Full Midnight Black
Materials
SGCC, Polymer, Mesh
Dimensions
(W/H/D)
211.8 x 549.6 x 503.6 mm / 8.3" x 21.6" x 19.8"
Net Weight
8.3 kg / 18.3 lbs
M/B Type
Micro-ATX, ATX
5.25" Drive Bays
3 (exposed)
3.5" Drive Bays
7 (hidden)
2.5" Drive Bays
2 (hidden converted from one 3.5 bay) , ”
I/O Panel
USB 3.0 x 1 (internal), USB 2.0 x 2, Mic x1,
Audio x 1 (supports AC97 / HD audio)
Expansion Slots
7
Cooling System
Front: 120mm red LED fan x 1
(can install 120mm fan x 2)
Rear: 120mm black fan x 1
Top: 120mm fan x 1 (optional)
Bottom:120mm fan x 1 (optional)
Side: 120mm fan x 2 (optional)
Power Supply
PS2 (optional)
Maximum
Compatibility
VGA card length:
281mm / 11.06" (with HDD cage)
400mm / 15.7" (without HDD cage)
CPU cooler height: 157mm / 6.2 inch
EAN Code
4719512039472
UPC Code
884102018848
Carton Size
560 x 280 x 595 mm
(L x W x H)
(22 x 11 x 23.4 inch)
Pallet Size
1125 x 1125 x 120 mm
(L x W x H)
(44.3 x 44.3 x 4.7 inch)
Container
w/ pallet
Cnt/pallet
w/o pallet
20’
280
28
320
40’
560
28
672
40’ HQ
640
32
735
Package Information
K550
RC-K -KWN1550
2 years
Features
Specifications
Warranty
Probleemoplossing CoolerMaster k550
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Zwart |
| Gewicht: | 8300 g |
| Breedte: | 211.8 mm |
| Diepte: | 503.6 mm |
| Hoogte: | 549.6 mm |
| Soort: | PC |
| Vormfactor: | Full Tower |
| Aantal USB 2.0-poorten: | 2 |
| Ingebouwde luidsprekers: | Nee |
| Audio-ingangen: | Ja |
| Audio-uitgang: | Ja |
| Materiaal: | SGCC |
| Aantal 2.5" bays: | 2 |
| Aantal 5.25" bays: | 3 |
| Aantal 3.5" bays: | 7 |
| Ondersteunde HDD-groottes: | 2.5, 3.5 " |
| Aantal uitbreidingssleuven: | 7 |
| Supported motherboard form factors: | ATX, Micro ATX |
| Zijraam: | Ja |
| Maximum CPU cooler hoogte: | 157 mm |
| Maximum grafische kaart lengte: | 400 mm |
| Maximale aantal ventilators voorkant: | 1 |
| Voorste ventilators ondersteunende diameters: | 120 mm |
| Maximaal aantal ventilators bovenkant: | 1 |
| Bovenste ventilators ondersteunende diameters: | 120 mm |
| Maximaal aantal ventilators achterkant: | 1 |
| Achterkant ventilators ondersteunende diameters: | 120 mm |
| Geïnstalleerde ventilators achterkant: | 1x 120 mm |
| Aantal geïntstalleerde ventilators voorkant: | 1x 120 mm |
| Maximaal aantal ventilators zijkant: | 2 |
| Zijkant ventilators ondersteunende diameters: | 120 mm |
| Maximaal aantal ventilators onderkant: | 1 |
| Ondersterste ventilators ondersteunende diameters: | 120 mm |
