Pagina 1/4
V650 SFX GOLD
MPY-6501-SFHAGV
MAKE IT MINI
The V SFX Gold delivers the high quality experience you’ve
come to expect from the V series in SFX form factor. Enjoy
the same great features with 80 Plus Gold efficiency, full-
modular cabling, an FDB fan, 16AWG PCIe high efficiency
cables, and a 10 year warranty. But now you can have it in a
mini-ITX case. With the V SFX Gold, the V series is now viable
for cases ranging from mini-ITX all the way up through E-
ATX systems. And with the included bracket this unit is
compatible with all of them.
FEATURES
SPECIFICATIONS
SFX Form Factor : This unit is compatible with all SFX cases and
suitable for mini-ITX system builds.
SFX- -ATX Bracket :to The included bracket allows users to install
this unit securely in traditional ATX cases.
80 PLUS Gold Certified : This certification guarantees a typical
efficiency of 90% under normal operating conditions.
Quiet FDB Fan : The 92mm FDB fan delivers effective, quiet, and
efficient cooling.
Full-Modular Cabling : Modular cables reduce clutter, increase
airflow, and improve overall efficiency and thermal performance.
10 Year Warranty : This unit comes with a standard limited
manufacturing warranty of 10 years from the date of purchase.
PACKAGE INFORMATION
Cable Type
EAN
UPC
MPY- -SFHAGV- 6501 US
4719512098370
884102070679
MPY- -SFHAGV- 6501 UK
4719512098387
884102070686
MPY- -SFHAGV- 6501 EU
4719512098394
884102070693
MPY- -SFHAGV- 6501 ST
4719512098400
884102070709
MPY- -SFHAGV- 6501 AU
4719512098417
884102070716
MPY- -SFHAGV- 6501 BR
4719512098424
884102070723
MPY- -SFHAGV- 6501 KR
4719512098431
884102070730
MPY- -SFHAGV- 6501 TW
4719512098448
884102070747
MPY- -SFHAGV- 6501 JP
4719512098455
884102070754
MPY- -SFHAGV- 6501 IN
4719512098462
884102070761
MPY- -SFHAGV- 6501 WO
4719512098479
884102070778
Nett Weight
1.41 kg
Gross Weight
1.85 kg
Package Dimensions
260 x 190 x 100mm (10.24 x 7.48 x 3.94")
Carton Dimensions
520 x 275 x 215mm (20.47 x 10.83 x 8.46")
Unit / Carton
5 pcs
Carton / Pallet
24 pcs
Product Name
V650 SFX Gold
Item Code
MPY- -SFHAGV 6501
ATX Version
SFX 12V Ver. 3.42
PFC
Active PFC
Input Voltage
100-240V
Input Current
8- 4A
Input Frequency
50-60Hz
Dimensions (L x W x H)
100 x 125 x 63.5mm
Fan Size
92mm
Fan Bearing
FDB
Efficiency
90% @ Typical Load
80 PLUS Rating
80 PLUS Gold
ETA Rating
Gold
lAMBDA Rating
Standard++
ErP 2014 Lot 3
Yes
Operating Temperature
0~50°C
Power Good Signal
100-500ms
Hold Up Time
16ms
MTBF
>100,000 hours
Protections
OVP / OPP / SCP / OCP / UVP / OTP /
Surge and Inrush Protection
Regulatory
TUV, cTUVus, CE, BSMI, FCC, CCC, EAC,
RCM, KCC, CB, UKCA
Connectors
ATX 24 Pin
x1 = 1x (300mm)
EPS 4+4 Pin
x1 = 1x (450mm)
EPS 8 Pin
x1 = 1x (450mm)
SATA
x8 = 2x (100+115+115+115mm)
Peripheral 4 Pin
x4 = 1x (100+115+115+115mm)
PCI-e 6+2 Pin
x4 = 2x (400+120mm)
AC INPUT
100 4A 50-240V~, 8- , -60Hz
DC OUTPUT
+3.3V
+5V
+12V
- 12V
+5Vstb
20A
20A
54.1A
0.3A
3A
TOTAL POWER
120W
649.2W
3.6W
1 5A
650W
Probleemoplossing CoolerMaster V650 SFX Gold
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Zwart |
| Gewicht: | 1760 g |
| Breedte: | 125 mm |
| Diepte: | 100 mm |
| Hoogte: | 63.5 mm |
| Geluidsniveau: | - dB |
| Gewicht verpakking: | 2060 g |
| Breedte verpakking: | 190 mm |
| Diepte verpakking: | 260 mm |
| Hoogte verpakking: | 100 mm |
| Type verpakking: | Doos |
| Stroom: | 8 - 4 A |
| Aan/uitschakelaar: | Ja |
| Certificering: | TUV, cTUVus, CE, BSMI, FCC, CCC, EAC, RCM, KCC, CB |
| Bedoeld voor: | PC |
| Aantal ventilatoren: | 1 ventilator(en) |
| Stroomspanning bescherming: | Over power, Over voltage, Overcharge, Overheating, Short circuit, Under voltage |
| 80 PLUS certificatie: | 80 PLUS Gold |
| Mean time between failures (MTBF): | 100000 uur |
| Totaal vermogen: | 650 W |
| Type koeling: | Actief |
| Efficientie: | 90 procent |
| AC-ingangsspanning: | 90 - 264 V |
| AC-ingangsfrequentie: | 47 - 63 Hz |
| Bedrijfstemperatuur (T-T): | 0 - 50 °C |
| Code geharmoniseerd systeem (HS): | 84733020 |
| Ventilator diameter: | 92 mm |
| ATX Power connector (24-pin): | Ja |
| EPS power connector (8-pin): | Ja |
| Motherboard power connector: | 24-pin ATX |
| Peripheral (Molex) power connectors (4-pin): | 4 |
| Vormfactor van de voeding (PSU): | SFX |
| Bearing technologie: | FDB |
| Power Factor Correctie (PFC) type: | Actief |
| Gecombineerd vermogen (+3.3V): | 120 W |
| Gecombineerd vermogen (+12V): | 650 W |
| Gecombineerd vermogen (+5V): | 120 W |
| Max huidige output (+3.3V): | 20 A |
| Max huidige output(+12V): | 54.1 A |
| Max huidige output (+5V): | 20 A |
| Max huidige output (-12V): | 0.3 A |
| Max huidige output (+5Vsb): | 3 A |
| Aantal SATA power connectors: | 8 |
| Bekabelingstype: | Modulair |
| ATX version: | 3.42 |
| Houd-tijd: | 16 ms |
| PCI Express power connectors (6+2 pin): | 4 |
| Vertragingsbereik Power Good-signaal: | 100 - 500 ms |
| EPS-voedingsconnector (4+4 pin): | Ja |
