V750 SFX GOLD WHITE EDITION
MPY-7501-SFHAGV
MAKE IT MINI
The V SFX Gold - white edition delivers the high quality
experience you’ve come to expect from the V series in SFX
form factor. Enjoy the same great features with 80 Plus
Gold efficiency, full-modular cabling, an FDB fan, 16AWG
PCIe high efficiency cables, and a 10 year warranty. But now
you can have it in a mini-ITX case. With the V SFX Gold -
white edition, the V series is now viable for cases ranging
from mini-ITX all the way up through E-ATX systems. And
with the included bracket this unit is compatible with all of
them.
FEATURES
SPECIFICATIONS
SFX Form Factor : This unit is compatible with all SFX cases and
suitable for mini-ITX system builds.
SFX- -ATX Bracket :to The included bracket allows users to install
this unit securely in traditional ATX cases.
80 PLUS Gold Certified : This certification guarantees a typical
efficiency of 90% under normal operating conditions.
Quiet FDB Fan : The 92mm FDB fan delivers effective, quiet, and
efficient cooling.
Full-Modular Cabling : Modular cables reduce clutter, increase
airflow, and improve overall efficiency and thermal performance.
10 Year Warranty : This unit comes with a standard limited
manufacturing warranty of 10 years from the date of purchase.
PACKAGE INFORMATION
Cable Type
EAN
UPC
MPY- -SFHAGV-WU, A/US Cable 7501
4719512118047
884102090363
MPY- -SFHAGV-WK, A/UK Cable 7501
4719512118054
884102090370
MPY- -SFHAGV-WE, A/EU Cable 7501
4719512118061
884102090387
MPY- -SFHAGV-WS, A/ST Cable 7501
4719512118078
884102090394
MPY- -SFHAGV-WA, A/AU Cable 7501
4719512118085
884102090400
MPY- -SFHAGV-WB, A/BR Cable 7501
4719512118092
884102090417
MPY- -SFHAGV-WY, A/KR Cable 7501
4719512118108
884102090424
MPY- -SFHAGV-WT, A/TW Cable 7501
4719512118115
884102090431
MPY- -SFHAGV-WJ, A/JP Cable 7501
4719512118122
884102090448
MPY- -SFHAGV-WI, A/IN Cable 7501
4719512118139
884102090455
MPY- -SFHAGV-WW, A/WO Cable 7501
4719512118146
884102090462
Nett Weight
1.42 kg
Gross Weight
1.86 kg
Package Dimensions
260 x 190 x 100mm (10.24 x 7.48 x 3.94")
Carton Dimensions
520 x 275 x 215mm (20.47 x 10.83 x 8.46")
Unit / Carton
5 pcs
Carton / Pallet
24 pcs
Product Name
V750 SFX Gold white edition
Item Code
MPY- -SFHAGV 7501
ATX Version
SFX 12V Ver. 3.42
PFC
Active PFC
Input Voltage
100-240V
Input Current
10 5A-
Input Frequency
50-60Hz
Dimensions (L x W x H)
100 x 125 x 63.5mm
Fan Size
92mm
Fan Bearing
FDB
Efficiency
90% @ Typical Load
80 PLUS Rating
80 PLUS Gold
ETA Rating
Gold
lAMBDA Rating
Standard+
ErP 2014 Lot 3
Yes
Operating Temperature
0~50°C
Power Good Signal
100-500ms
Hold Up Time
16ms
MTBF
>100,000 hours
Protections
OVP / OPP / SCP / OCP / UVP / OTP /
Surge and Inrush Protection
Regulatory
TUV, cTUVus, CE, BSMI, FCC, CCC, EAC,
RCM, KCC, CB, UKCA
Connectors
ATX 24 Pin
x1 = 1x (300mm)
EPS 4+4 Pin
x1 = 1x (450mm)
EPS 8 Pin
x1 = 1x (450mm)
SATA
x8 = 2x (100+115+115+115mm)
Peripheral 4 Pin
x4 = 1x (100+115+115+115mm)
PCI-e 6+2 Pin
x4 = 2x (400+120mm)
AC INPUT
100 5A-240V~, -10 , -60Hz 50
DC OUTPUT
+3.3V
+5V
+12V
- 12V
+5Vstb
20A
20A
62.5A
0.3A
3A
TOTAL POWER
120W
750W
3.6W
1 5W
750W
Probleemoplossing CoolerMaster V750 SFX Gold
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Zwart |
| Gewicht: | 1761 g |
| Breedte: | 125 mm |
| Diepte: | 100 mm |
| Hoogte: | 63.5 mm |
| Geluidsniveau: | - dB |
| Gewicht verpakking: | 2061 g |
| Breedte verpakking: | 190 mm |
| Diepte verpakking: | 260 mm |
| Hoogte verpakking: | 100 mm |
| Type verpakking: | Doos |
| Stroom: | 10 - 5 A |
| Aan/uitschakelaar: | Ja |
| Certificering: | TUV, cTUVus, CE, BSMI, FCC, CCC, EAC, RCM, KCC, CB |
| Bedoeld voor: | PC |
| Aantal ventilatoren: | 1 ventilator(en) |
| Stroomspanning bescherming: | Over power, Over voltage, Overcharge, Overheating, Short circuit, Under voltage |
| 80 PLUS certificatie: | 80 PLUS Gold |
| Mean time between failures (MTBF): | 100000 uur |
| Totaal vermogen: | 750 W |
| Type koeling: | Actief |
| Efficientie: | 90 procent |
| AC-ingangsspanning: | 90 - 264 V |
| AC-ingangsfrequentie: | 47 - 63 Hz |
| Bedrijfstemperatuur (T-T): | 0 - 50 °C |
| Code geharmoniseerd systeem (HS): | 84733020 |
| Ventilator diameter: | 92 mm |
| ATX Power connector (24-pin): | Ja |
| EPS power connector (8-pin): | Ja |
| Motherboard power connector: | 24-pin ATX |
| Peripheral (Molex) power connectors (4-pin): | 4 |
| Vormfactor van de voeding (PSU): | SFX |
| Bearing technologie: | FDB |
| Power Factor Correctie (PFC) type: | Actief |
| Gecombineerd vermogen (+3.3V): | 120 W |
| Gecombineerd vermogen (+12V): | 750 W |
| Gecombineerd vermogen (+5V): | 120 W |
| Max huidige output (+3.3V): | 20 A |
| Max huidige output(+12V): | 62.5 A |
| Max huidige output (+5V): | 20 A |
| Max huidige output (-12V): | 0.3 A |
| Max huidige output (+5Vsb): | 3 A |
| Aantal SATA power connectors: | 8 |
| Bekabelingstype: | Modulair |
| Houd-tijd: | 16 ms |
| PCI Express power connectors (6+2 pin): | 4 |
| Vertragingsbereik Power Good-signaal: | 100 - 500 ms |
| EPS-voedingsconnector (4+4 pin): | Ja |
