Costar CDC3124VW Handleiding
Hier is de Costar CDC3124VW (Bewakingscamera) gebruikershandleiding. 1 pagina's in taal Engels met een gewicht van 0.5 Mb. Als u geen antwoorden op uw probleem kunt vinden Vraag het onze community.
Pagina 1/1
Vandal Resistant Dome Camera
Accessories
Installation
Specifications
Dimensions
Step.1
Cable
Part name & Dimension
Step.3
Features
1/3.2” SONY 1.3M STARVIS CMOS
1280 (H) X 960(V) = 1000 TVL
Auto Compensaon & Long range transmission
2.4mm Megapixel Fixed lens
DEFOG funcon
Real WDR 120dB (Wide Dynamic Range)
Live Defect Detecon & Correction
Flush vandal dome with surface base
3-axis gimbal bracket
Anti-vibration design
Weather proof / IP-66 compliant
DC12V
All specification and pictures are subject to change without notice to improve quality.
Step.2
POWER
CAUTION! Please use regulated power supply DC12V 300mA
Reverse Polarity Protection
VIDEO
Model (NTSC / PAL)
Image Sensor 1/3.2” SONY 1.3M STARVIS CMOS
Video Output NTSC : 59.94fps output
PAL : 50fps output
Acve pixel 1297 (H) x 977 (V). 1.27Mpixels
Recording pixel 1280 (H) x 960 (V). 1.23Mpixels
Auto control funcon Auto exposure (AE) control,
Auto white balance (AWB) control
WDR applied 120dB
Image ip Vercal, Horizontal
Privacy Masking
Area masking by
monotone overlay or mosaicking
(up to 16 area)
Power Source DC12V ±10%
Power Consumpon Max 1.0 Wa
Operang Temperature - to 8530℃ ℃
Operating Humidity 10% to 90%
Lens 2.4mm Megapixel Fixed lens
Dimension/mm
Flush
61mm(D) X 82.4mm(L)
Surface
66.4mm(D) X 82.4mm(L)
Weight/g 400g
