CCS-UC-1-AV-PLUS
Crestron Mercury® – Tabletop UC Video Conference System w/Professional Camera
crestron.com | 800.237.2041
>The ultimate tabletop AV conferencing solution for any
UC platform
>Present, call, conference, and collaborate — all through one
amazing tabletop device!
>Simple, intuitive touch screen UX — provides a consistent user
experience in every room
>Customizable front-of-room experience on the room display
>A complete kit solution — just add a display and mount
>Easy to specify and install — no custom design,
programming, or software installation required!
>Easy to provision and manage through Crestron®
XiO Cloud™
>Connects and communicates securely over any
enterprise or SMB network
>Full open SIP conferencing speakerphone
>Bluetooth® pairing with mobile phones
>USB connectivity for laptops running web conferencing or
other software
>Native Skype® for Business VoIP support
>Professional-quality HD USB room camera
>AirMedia® 2.0 wireless BYOD presentation and content sharing
[1]
>HDMI® input for laptop and other AV content sources [2]
>DisplayPort and USB-C™ input via optional Multihead cable
(sold separately)
>HDMI output for room display device
>Exceptional full-duplex audio performance
>Extremely natural 2-way wideband voice quality
>Integrated 360° quad microphone array
>High-powered full-range speaker
>Limes Audio TrueVoice® AEC technology
>High-visibility mic mute indication
>Available add-on mic pods for extra coverage
>7” (178 mm) HD color touch screen
>LDAP corporate directory access
>Active Directory® authentication
>Room scheduling integration with Microsoft®
Exchange or Crestron Fusion®
>Built-in PinPoint™ beacon for use with the
Crestron PinPoint App [4]
>Built-in PIR occupancy detector
>Persistent occupancy awareness combining
motion and voice detection
>IoT cloud based provisioning and management
>Web browser configuration
>Enterprise-grade security
>Dual LAN ports
>PoE+ or AC line powered [3]
>100-240V universal power pack included
>CEC, IP, IR, or RS-232 display control
>Power management and scheduling
>Optional 180° swivel mount kit available
>Optional display and camera extender solutions available
>Complete kit contains the Crestron Mercury® tabletop console,
Huddly™ GO camera, cables, and power supply
The Crestron Mercury Tabletop UC Video Conference System
(CCS-UC-1-AV-PLUS) provides a complete video conference room solution
for open-platform UC applications. In one stunning tabletop console device,
Crestron Mercury comprises a high-performance, full-duplex conferencing
speakerphone and touch screen controller with extensive connectivity
options for BYOD devices and networked solutions. The complete system
includes cables, power supply, and professional quality camera.
The Crestron Mercury system enables audio and video conferencing,
collaboration, and content sharing using any UC platform. It works with any
Crestron Mercury®
Crestron Mercury is a remarkable tabletop console device engineered to provide a
superior conferencing and collaboration experience for enterprise and SMB applications.
It is available in multiple forms, including models for “Open UC” audio or video
conferencing applications, as well as models dedicated for use with the Microsoft
Teams® IC platform as part of a complete kit solution. In any huddle Crestron Flex
space, meeting room, or executive office, Crestron Mercury delivers a distinctively
simple and consistent user experience in all the places people work and meet.
Built on the IoT cloud based XiO Cloud™ platform, Crestron Mercury empowers IT
administrators and AV integrators to deploy, manage, monitor, and thousands of evolve
networked UC devices — simply, quickly, and securely — all from a single dashboard.
By standardizing on Crestron Mercury, any organization can realize a more productive
and stress-free workplace through greater acceptance and utilization of UC
technology that’s truly easy to use.
Probleemoplossing Crestron CCS-UC-1-AV-PLUS
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Zwart |
| Ingebouwd display: | Ja |
| Bluetooth: | Ja |
| Beeldscherm: | LCD |
| Beeldschermdiagonaal: | 7 " |
| Resolutie: | 1280 x 800 Pixels |
| Touchscreen: | Ja |
| Bluetooth-versie: | 4.0 |
| USB-connectortype: | Micro-USB B, USB Type-A |
| Ethernet LAN: | Ja |
| Ondersteunde video-modi: | 720p |
| Meegeleverde kabels: | HDMI, LAN (RJ-45), Micro-USB, USB, USB Type-A to USB Type-C |
| Touch screen type: | Capacitief |
| Maximale beeldsnelheid: | 30 fps |
| Resolutie bij opnamesnelheid: | 1280x720@30fps |
| Inclusief AC-adapter: | Ja |
| Aantal USB 2.0-poorten: | 3 |
| Soort serieële aansluiting: | RS-232 |
| Microfoon, line-in ingang: | Ja |
| Aantal Ethernet LAN (RJ-45)-poorten: | 2 |
| Ingebouwde luidsprekers: | Ja |
| Gemiddeld vermogen: | 11 W |
| DC voltage input: | 24 V |
| Aansluiting voor netstroomadapter: | Ja |
| Megapixels: | 16 MP |
| Type beeldsensor: | CMOS |
| Beeldsensorformaat: | 1/2.3 " |
| HD type: | HD |
| Ondersteunde grafische resoluties: | 1280 x 720 (HD 720) |
| Ingebouwde camera: | Ja |
| Ruisonderdrukking: | Ja |
| Ethernet LAN, data-overdrachtsnelheden: | 10, 100 Mbit/s |
| Temperatuur bij opslag: | -20 - 70 °C |
| Ondersteunde netwerkprotocollen: | IEEE 802.1X, Active Directory authentication, LDAP, Kerberos, SSL, TLS, SSH, SFTP (SSH File Transfer Protocol), SRTP, digest access authentication, password login, HTTPS secure provisioning, XiO Cloud client |
| Ondersteuning voor statiefmontage: | Nee |
| Frequentiebereik: | 90 - 22000 Hz |
| Ophangsysteem voor aan de muur: | Nee |
| Bewegingssensor: | Ja |
| Aantal personen: | - persoon/personen |
| Lens type: | Ultragroothoek |
| AC-ingangsspanning: | 100 - 240 V |
| AC-ingangsfrequentie: | 50 - 60 Hz |
| Bedrijfstemperatuur (T-T): | 0 - 35 °C |
| Relatieve vochtigheid in bedrijf (V-V): | 5 - 95 procent |
| Type product: | Videovergaderingssysteem voor groepen |
| Aantal Power over Ethernet plus (PoE +)-poorten: | 2 |
| 3D-geluidsreductie: | Ja |
| Camera gewicht: | 110 g |
| Stroom via Ethernet (PoE): | 25.5 V |
| Bewegingssensor afstand: | 1.83 m |
| Effectieve sensor resolutie: | 16 MP |
| Horizontaal gezichtsveld: | 120 ° |
| Afmetingen camera (BxDxH): | 40 x 72 x 33 mm |
| Afmetingen interfacemodule (B x D x H): | 227 x 324 x 105 mm |
| Microfoon pick-up bereik: | 6 m |
| DC-uitgangspoort interfacemodule: | Ja |
| Aantal HDMI-poorten interfacemodule: | 2 |
| Telepresence: | Ja |
| Aantal interfacemodule HDMI-uitvoerpoorten: | 1 |
| Aantal interfacemodule HDMI-invoerpoorten: | 1 |
| Netwerkkabellengte: | 3.66 m |
