CLW-SLVU-P
Cameo
®
In-Wall Remote Dimmer, 120V
crestron.com
|
800.237.2041
>Replaces traditional 3- or 4-way dimmers and switches
>Matches the popular Cameo
®
style
>Provides control to the connected dimmer or switch
(CLW-DIMEX-P, CLW-SWEX-P, and CLW-DELVEX-P)
[1, 2]
>Field-replaceable button caps
>Customizable button engraving
[3]
>Configurable with rocker or 2 large button caps
>Available in all designer colors
The CLW-SLVU-P is a Cameo
®
in-wall remote dimmer that provides control
to Crestron
®
Cameo
®
dimmers and switches.
[1]
Available in designer colors
and configurable with 2 buttons or in a rocker layout, the CLW-SLVU-P
uses a "universal" design, capable of controlling CLW-DIMEX-P,
CLW-SWEX-P, and CLW-DELVEX-P dimmers and switches.
Multipoint Dimming and Switching
Similar to traditional 3- or 4-way circuits, the CLW-SLVU-P lets you control
the lights from multiple locations using the “traveler” wire.
[1]
The remote
dimmer does not need to be programmed, providing instant usability upon
installation. Up to 9 CLW-SLVU-Ps can be connected to a single Cameo
dimmer.
Field-Replaceable Button Caps
Like Cameo dimmers and switches, the button caps on the CLW-SLVU-P can
be swapped in the field, making it easy to change engraving or color after
installation. Use the rocker button cap or the two large button caps to match
the look of the connected dimmer or switch.
SPECIFICATIONS
Power Requirements
Line Power: 120 Volts AC, 50//60Hz
Buttons & Indicators
Buttons: Configurable with (1) rocker or (2) large button caps to control the
connected dimmer or switch
[1]
LED Feedback: (1) White LED light pipe pinhole displays status (on/off) of
the connected dimmer or switch
Connections
Line: (1) Captive screw terminal, black, line power input
Neutral: (1) Captive screw terminal, white, line power input
Remote: (1) Captive screw terminal, blue, remote control to CLW-DIMEX-P,
CLW-SWEX-P, and CLW-DELVEX-P
Ground: (1) Captive screw terminal, green, ground
Environmental
Temperature: 32° to 104° F (0° to 40° C)
Humidity: 10% to 90% RH (non-condensing)
Construction
Keypad: Plastic; textured or smooth
Faceplate: Requires a decorator-style faceplate (FP-G Series
[1]
)
Mounting: Mounts in a 1-gang (or larger) 3-1/2 inch (89 mm) deep
electrical box (not included), gangable
Dimensions
Height: 4.13 in (105 mm)
Width: 1.75 in (45 mm)
Depth: 1.75 in (45 mm)
Note: Dimensions shown are without a faceplate.
Weight
5 oz (142 g)
Probleemoplossing Crestron CLW-SLVU-P-A-T
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Breedte: | 44 mm |
| Diepte: | 44 mm |
| Hoogte: | 105 mm |
| Soort: | Dimmer |
| Bedrijfstemperatuur (T-T): | 0 - 40 °C |
| Relatieve vochtigheid in bedrijf (V-V): | 10 - 90 procent |
