ESSENCE IW8
Essence® 8” 2-Way In-Wall Speakers
crestron.com | 800.237.2041
>Ultimate performance 2-way in-wall speakers
>8” woven Kevlar® woofers
>1.1” advanced synthetic polymer dome tweeters
>Precision 4th order crossovers
>Cast aluminum woofer baskets
>Extra large magnets and vented pole pieces
>“Zero-bezel” frameless steel grilles, paintable
>Spring-loaded toggle clamp mounting system
>175 Watts program power handling
>38Hz-20kHz frequency response
>8 Ohms nominal impedance
>Sold in pairs
The product of expert Crestron
® audio engineering, Essence®
speakers deliver the pinnacle of performance for demanding
residential installations. Select esoteric materials, top shelf
components and a refined, high-end appearance underscore the
meticulous design behind each model. The result is a complete line
of in-wall and in-ceiling speakers worthy of a place in every room
of the finest custom home.
The Essence line promises the ultimate in installed audio design,
delivering simply stunning sound quality while minimizing any impact on
your decor thanks to paintable zero-bezel grilles. Streamlined installation
of each speaker is facilitated through a spring-loaded toggle clamp
mounting system.
The Essence IW8 model provides a pair of 2-way in-wall speakers
featuring 8 inch long-throw woven Kevlar® woofers for deep, defined low
end, and large 1.1 inch advanced synthetic polymer dome tweeters for
crisp, fluent highs, articulate midrange, and consistent coverage across a
wider listening area. Cast aluminum woofer baskets assure pure,
uncolored bass response. Precision 4th order crossovers utilizing the
highest quality components ensure a full, rich and detailed response
across the spectrum. Power handling is an impressive 175 Watts
(program), with a wide frequency response from 38 Hz to 20 kHz (±3 dB).
SPECIFICATIONS
Features & Performance
Woofer: 8 inch (203 mm) woven Kevlar® w/rubber surround, vented pole
piece & cast aluminum basket
Tweeter: 1.1 inch (28 mm) advanced synthetic polymer dome, ferrofluid
cooling, damped aperiodic rear chamber
Crossover: 4th order Linkwitz-Riley
Crossover Frequency: 2 kHz
Impedance: 8 Ohms nominal
Frequency Response: 38 Hz to 20 kHz (±3 dB)
Frequency Range: 30 Hz to 20 kHz (-10 dB)
Power Handling: 175 Watts program
Sensitivity: 91.5 dB @ 1W/1m
Connections
Input: (2) spring terminals;
Maximum Wire Size: 10 AWG
Environmental
Temperature: 41° to 104°F (5° to 40°C)
Humidity: 10% to 90% RH (non-condensing)
For indoor use only
Construction
Baffle: ABS plastic, black
Grille: Steel with white textured finish, paintable, magnetically-held “zero-
bezel” frameless design
Mounting: Flush wall mount using 6 integral spring-loaded toggle clamps,
1.35 in (34 mm) maximum surface thickness, 4.33 in (110 mm) minimum
mounting depth, 13.3 in (338 mm) high x 9.8 in (249 mm) wide recom-
mended cutout
Dimensions
Height: 13.91 in (354 mm)
Width: 10.45 in (266 mm)
Depth: 4.50 in (115 mm)
Dimensions shown are per speaker, positioned vertically
Weight
7.54 lb (3.42 kg) per speaker
