l
Provides a 180° visual indication of a meeting room's
availability for TSW-1070 or TSS-1070 series touch screens
l
Features a stylish appearance designed to complement
corporate office environments
l
Illuminates vivid green or red to clearly indicate room status
l
Supports RGB color mixing to allow for almost any color
illumination
l
Energy efficient at less than 2 W power consumption
l
Mounts easily to the rear of the touch screen
l
Single-wire USBconnectivity
l
Compatible with various in-wall, multisurface, and mullion
mounting accessories
l
Available in smooth black or white finish
The Crestron® TSW-1070-LB is a room availability light bar
designed for use with TSW-1070 TSS-1070or series touch
screens. The TSW-1070-LB provides a 180° visual indication of
a room’s availability as part of a complete enterprise room
scheduling solution. The TSW-1070-LB mounts easily to the
rear of the touch screen and illuminates bright green or red to
indicate the room availability status, with options for custom
color mixing and programming. The TSW-1070-LB features a
clean, stylish appearance and vivid color illumination that
complement any corporate office environment, and it is energy
efficient at less than 2W power consumption.
Roo
Roo
Roo
RooRoom
m
m
mm A
A
A
AAva
va
va
vavailab
ilab
ilab
ilabilabilit
ilit
ilit
ilitility
y
y
yy St
St
St
StSta
a
a
aat
t
t
ttus
us
us
usus
For room scheduling applications, the TSW-1070-LB simply
connects to the touch screen via USBand requires no special
programming or configuration.
1
The illumination color is
controlled by the room scheduling application, which runs on the
touch screen and syncs with the Crestron Fusion® software or
another room scheduling application. The TSW-1070-LB
illuminates green when the room is available and red when the
room is occupied. It can also blink to indicate an emergency
message broadcast from Crestron Fusion.
Cust
Cust
Cust
CustCustom
om
om
omom RGB
RGB
RGB
RGBRGB Colo
Colo
Colo
ColoColor
r
r
rr Mixin
Mixin
Mixin
MixinMixing
g
g
gg
For custom applications, the TSW-1070-LB can be configured
to illuminate in almost any desired color. The TSW-1070-LB
features tricolor RGB LEDs that allow for a full spectrum of
colors by blending the red, green, and blue elements in 1%
increments. Custom RGB color mixing is performed either
through the touch screen directly or via custom control system
programming. A Crestron control system connected to the
touch screen can be programmed to support various
functionality, enabling colors to alternate, fade in and out, or
blink on and off as desired.
2
V
V
V
VVe
e
e
eersa
rsa
rsa
rsarsat
t
t
ttile
ile
ile
ileile Moun
Moun
Moun
MounMountin
tin
tin
tinting
g
g
gg Op
Op
Op
OpOptio
tio
tio
tiotions
ns
ns
nsns
The TSW-1070-LB is compatible with various TSW-70 series
mounting solutions to support installations common for room
scheduling touch screens, including the TSW-70-UMBuniversal
mounting bracket, the TSW-1070-MSMKmultisurface mount
kit, and the TSW-770/1070-MUMKmullion mount kit.
TS
TS
TS
TSTSW-
W-
W-
W-W-1
1
1
11070
070
070
070070-LB
-LB
-LB
-LB-LB
Room Availability Light Bar for TSW-1070 Series
