OVERVIEW
The Web-based AM524 includes an embedded
access control application for system
administration, user setup and event viewing
that is accessed via any standard Web browser
over a 10/100 Mbps Ethernet network.
The AM 524 supports from one to 24 readers
using supporting Door Units. The flexibility of
a modular design while supporting local power to
connected readers makes the AM524 easy to install.
The AM524 supports all standard access control readers utilizing an RS485 and Wiegand
data connection through connected Door Units.
Supporting RS485 communication between modules, the AM524 provides a scalable
solution by simply adding additional Door Units. Up to twelve Door Units connect to an
AM524 module, with each supporting two reader connections, for a total of 24 readers.
Up to four Access Managers can communicate in a cluster configuration, providing for
expansion and administration of up to 96 readers.
STANDARDS SUPPORT
The AM524 was developed around open standards supporting SOAP/REST Web Service
communication for easy integration, XML data format and platform-independent
Java application software. The integrated Web server and embedded access control
application allow for easy access and setup via any Web browser. This eliminates the need
for traditional PC-based servers and client-side administration software.
EASY TO USE
To access the embedded access control application, simply select a network-connected
AM524 under Network devices within Windows (UPnP) or type in the IP address of an
AM524 directly into any Web browser, log in to the system and the application menu is
displayed. The Access Manager activity tables are easily accessed via the Web interface. All activity such as access requests and system
events are stored in an XML events log.
Access Manager
AM524
Features
• Up to 24 readers locally,
96 readers clustered
• Access and system status reporting
• 10/100 Mbps Ethernet connection
• Embedded access control
application software
• Administration through standard
Web browser
• RS485 communication with Door Units
• Upload configuration and events data
to FTP/SCP host
• Built-in Web server
• Alert notification via e-mail
• Universal plug and play (UPnP)
• SOAP/REST Web Service support
• Local 30,000 users/40,000 events
• Supports all standard readers
Compatibility
The AM524 supports all standard access
reader types:
• Fingerprint Key (Kaba I.AM)
• HID proximity
• HID iCLASS
• AWID
• Legic
• MIFARE
• EM
• Hitag
• Smart card
ISO 15693/ISO 14443A
Ax.S SerieS Embedded Access Control
