Abbildungen können nicht im Serien-Lieferumfang enthaltenes Zubehör darstellen / Illustrations can contain accessories, which are not included in standard extent of delivery.
Abbildungen ähnlich, produktionsbedingte Abweichung vorbehalten / Illustration similar (in design), production-wise modications reserved.
File: S:\shared-pool\Product-Documentation\T-Produktbeschreibung\30_n0t\Originale_Englisch_PA04\2255715_01017.doc
Erstelldatum/create date: 05.02.2008 13:47:00Aktualisiert/up dated: 06.11.2008
BT-EH 1000
Electric Hoist
Art.-No. 22.557.15
The start button is equipped with an emergency-cut-o button. This device guarantees a safe cut-o.
The start button is designed in insulation class II (safety insulated).
A forcibly actuated end switch assures that the hoist will safely be cut-off (roll up and roll o).
Also in case of a defect on the pressure spring (i. e. rupture of the wire) stopping of the load is assured.
The brake will be activated in case of power failure in the motor.
The non-twisting steel rope prevents twisting of the loads during the lifting motion.
The load hook with additional safety latch: This added latch prevents an unintended loosening of the load suspension
device.
The overload protection prevents the motor from overheating.
Features
Fastening with 2 double clamps (1)
Motor with thermal cut-o (2)
12 m steel wire rope (non-twisting,
Ø 5.6 mm) (3)
Control switch with emergency button (4)
Deection pulley with payload hook (5)
An automatic brake secures the load in
any position
Technical Data
Payload: 500 kg without pulley
999 kg with pulley
Lifting height: 11.5 m without pulley
5.7 m with pulley
Mains: 230 V ~ 50 Hz
Power: 1,600 W S3 25 %
Rope speed: without pulley:8 m/min
with pulley: 4 m/min
Net weight: 30.0 kg
Gross weight: 32.0 kg
Packing dimensions: 550 x 236 x 308 mm
Bar code: 4006825 539776
Sales unit: 1 pc
4
2
1
3
5
