Abbildungen können nicht im Serien-Lieferumfang enthaltenes Zubehör darstellen / Illustrations can contain accessories, which are not included in standard extent of delivery.
Abbildungen ähnlich, produktionsbedingte Abweichung vorbehalten / Illustration similar (in design), production-wise modications reserved.
File: S:\shared-pool\Product-Documentation\T-Produktbeschreibung\30_n0t\Originale_Englisch_PA04\2360340_01018.doc
Erstelldatum/create date: 19.09.2008 10:08:00Aktualisiert/up dated: 14.07.2010
Air Conditioner
Art.-No.: 23.603.40
MKA 3000 E
Bar code: 4006825555141
Sales unit: 1 pc
Mobile and compact air conditioner, which provides a comfortable indoor climate
.
Cooling and dehumidifying in one
unit. The unit is completely assembled and ready for service after the exhaust hose has been connected.
With soft keys and the remote control all operating levels can be set and also the air conditioner can be switched on/o.
The thermostat regulation provides a well-balanced indoor climate. This model is suitable for rooms of max. 80 m
3
volume.
Features:
- Large control panel (1)
- Air discharge opening lamellas are adjustable
mechanically in horizontal position (2)
- 4 pcs castors (3)
- Exhaust air hose with adaptor (L max. 150 cm) (4)
- Window gap covering (5)
- Air suction lter with activated carbon lter
- Remote control (6)
- Condensate return in the cooling operation – no
condensate box emptying necessary
- Integrated condense water box (approx. 1.2 l capacity)
- By very high humidity (> 80 %) is a constant drainage
via a condense water hose possible
- Diagnostic function in case of fault
Functions:
- LED-Display
- Temperature level: +18° C up to +32° C
- Fan speed: 2-settings
- Operating level section (Mode): Autom., cooling, fan,
sleeping
- Power on-time: 1 to 24 h, Continuous operation
-
Unit ON
-
OFF
LED
-
Display for:
- Unit ON
- Cooling, fan
- Fan speed
- Condense water box full
- Compressor running
- Timer ON
- Sleeping mode ON
- Temperature
Technical data:
- Coolant: R410A
- Energy-Eciency-Class: A
- EER / COP: 2.61 / -
- Energy consump. when cooling: 590 kWh per year
- Mains: 220 - 240 V ~ 50 Hz
- Cooling capacity: 3,080 W / 10,500 BTU/h
- Air circulation max.: 440 m³/h
- Exhausted room humidity
max. (30° C / 80% RH): approx. 29 l a day
- Quantity of coolant: 410 g
- Noise level: 56 dB (A) ≤
- Housing dimensions H x W x D: 754 x 365 x 395 mm
- Packing dimensions H x W x D: 778 x 548 x 423 mm
- Net weight approx.: 28 kg
- Gross weight approx.: 29 kg
Characteristics according to active standard EN 14511
1
2
3
4
6
5
