1 ENG IPERTU-MPS060 02 V00_0323
60W Power Supply Module
General Specifications :
* Universal Input Voltage 100-240 VAC (-15% .. +10%) 50/60 Hz
* 24VDC (±%10) Adjustable Output Voltage
* 2,5 A / 60 W @ 24 VDC
* Active Output Led indicator
* Can be connected to other IPERTU modules over IPERTU BUS
without cable connection (must be connected to left of the
modules connected to the IPERTU BUS)
IPERTU-MPS060-00-00-00-00_1
Electrical Specifications
Input
Input Voltage Range
100-240 VAC (-%15 + %10) 50/60 Hz
Efficiency
> 84%
Inrush Current
max 33A @ 230 VAC
Leakage Current
max 2.5mA
Output
Rated Power
60W 2,5 A @ 24 VDC
Adj. Voltage Range
24 VDC (±%10) Can be adjusted with Trimpot in the given range.
Ripple
300 mVpp max
Load Regulation
< %1,5
Line Regulation
< %1,5
Start Up Time
1200ms/230VAC
Hold Up Time
100ms/230VAC
Protections
Overload Protection
% 140
Short Circuit Protect.
Auto-recovery after error disappears.
Thermal Protection
When the ambient temperature rises above 55 °C, the output voltage reduced depending on
ambient temperature and load current.
Operation / Storage Environment
Operation Temp.
-20..+50 °C
Storage Temperature
-30..+75 °C
Protection Class
IP20
Pollution Degree
2
İsolation
* 3000 VAC isolation between Input and Output
* 1500 VAC isolation between Input and Earth
* 500 VAC isolation between Output and Earth
Dimensions (W*H*D)
50*100*70 mm
Weight
230 gr
Indıcators
Output
Output Led is ON when the output is in rated limits.
