Gamdias Athena P3 Handleiding
Hier is de Gamdias Athena P3 (Niet gecategoriseerd) gebruikershandleiding. 2 pagina's in taal met een gewicht van 2,447,200.0 Mb. Als u geen antwoorden op uw probleem kunt vinden Vraag het onze community.
Pagina 1/2
LED SWITCH
Front I/O cables
SATA Cable LED Switch Button Cable ARGB Cable PWM Cable
1. Lightly touch the LED button on the case to switch lighting effects.
2. Press and hold the LED button on the case to enter motherboard sync mode.
3. In motherboard sync mode, lightly touch the button to exit motherboard sync mode.
Motherboard Installation (hidden connector)
01 02 01 02
Fan Hub
Case Layout and Parts Identification
Power Supply Unit (PSU) InstallationPackage Contents
ATHENA
I
P3
MID-Tower PC Case
1
2
3
4
5
6
7
8
9
10
11
12
13
14
Ensure compatibility of all non-power connectors, RGB, USB, and fan controls.
Front I/O cables
Motherboard
Motherboard
Control Box
Motherboard
Motherboard Motherboard
IO Panel
LED Switch
Button Cable
HD Audio
Power Switch
USB 3.1 (Type C)
USB 3.0 ARGB Cable
LED Switch Button
1. Front Panel
2. Tempered Glass Panel
3. Top Dust Filter
4. Top Swappable Panel
5. Right Side Panel
6. Rear Fan
7. PCIe Slot Cover
8. IO Port Module
9. Front Fans
10. HDD/ SSD Cage
11. SSD Cage
12. Fan Hub
13. Bottom Dust Filter
14. Chassis Pedestals
1. Gaming Case : ATHENA P3
2. Chassis Protection : EPS Protection Foam
3. Chassis Dust Cover
4. Preinstalled Fans : Front 3 x 140mm PWM Fans Rear:1 x 120mm PWM Fans
6. Accessory Box :
A. Motherboard/ SSD screws (22)--------------------------------------------------------------
B. Motherboard additional standoffs (3)------------------------------------------------------
C. PSU/ GPU PCIe screws (6)-----------------------------------------------------------------------
D. HDD cage screws (9)---------------------------------------------------------------------------------
E. Fan screws (12)------------------------------------------------------------------------------------------
F. Motherboard Stand-off removal tool (1) --------------------------------------------------
G. Zip ties (5)--------------------------------------------------------------------------------------------------
H. Card Buckle (2) ------------------------------------------------------------------------------------------
ARGB Port
ARGB Cable Port
SATA Cable Port
PWM Cable Port
PWM Port
LED Switch Button
Cable Port
LED
