Dimensions and Installation Information (in inches)
For answers to your Monogram,
® GE Profile™ or
GE® appliance questions, visit our website at
geappliances.com or call GE Answer Center
®
service, 800.626.2000.
Specification Created 4/11 330556
All GE ranges are equipped with
an Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
Factory set for Natural gas. A set of LP orifices
is included with each range for LP conversion.
Gas Self-Clean Range Anti-Tip Bracket
(Part No. 205C1714P001)
Electrical Rating: 120V, 60Hz, 5A
Installation Information: Before installing,
consult installation instructions packed with
product for current dimensional data.
JGBS07SET
GE® 30" Free-Standing Standard Clean Gas Range
24
30
8
4
9
2
2-1/2
Recommended area for
thru the floor connection
of pipe stub and shut-off valve
Recommended area for
120V outlet on rear wall
and area for thru the wall
connection of pipe stub
and shut-off valve
Recommended common
area for gas outlet and
electrical outlet
C
L
* Dimension from wall
to front of closed
door handle is 29".
30
46-7/8
26-1/4*
46-1/4
36-1/4 ±1/4
* Dimension from wall
to front of closed
door handle is 29".
