C E R TIF I ED
Dimensions and Installation Information (in inches)
Factory set for Natural gas. A set of LP orifices is included with
each range for LP conversion.
Gas Self-Clean Range Anti-Tip Bracket
(Part No. 205C1714P001)
Electrical Rating: 120V, 60Hz, 5A
Installation Information: Before installing, consult installation
instructions packed with product for current dimensional data.
For answers to your Monogram,® GE Profile™ or
GE® appliance questions, visit our website at
ge.com or call GE Answer Center® service,
800.626.2000.
All GE ranges are equippe d with
an Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
JGBS18SER
GE® 30" Free-Standing Gas Range
Specification Created 5/10 330501
All 30" GE gas and electric range backguards
are 30-7/8" wide.*
Note: 30" ranges conform to U.L. requirements
for 0" spacing from adjacent walls below
countertops. To reduce possible scorching of
walls, engineering recommends a minimum of
1-1/2" spacing to allow for possible extended,
high heat, no-load heating element operation.
* Except these models: JGBS07, JGBS04, all GE
Profile free-standing electric and gas ranges
Fits most countertop backsplash applications.
Consult Use & Care Manual for detailed
installation instructions.
30-7/8"
24
30
8
4
9
2
2-1/2
Recommended area rfo
thru the floor connection
of pipe stub and shut-off evalv
Recommended area for
120V outlet on rear wall
and area for thru the wall
connection of pipe stub
and shut-off evalv
Recommended common
area for gas outlet and
electrical outlet
46-1/8
26-1/4*
46-3/8
36-1/4 1/4±
*Dimension from wall
front of closed to
door handle is 28-5/8".
30
