July 8, 2013 1
GV-NET/IO Card V3.2
The GV-NET/IO Card is a RS-485 / RS-232 interface converter, and provides 4 inputs and 4
relay outputs as well. It supports both DC and AC output voltages.
Key Features
• A USB port is provided for PC connection, and it is used with 30 DC output voltages.
• It can switch between two modes, NET/IO Card Mode and I/O Box Mode, which expand
its capability.
• Up to 4 GV-NET/IO Cards can be chained together when it is on the I/O Box Mode.
• It can act as an independent device when it is on the I/O Box Mode.
System Requirements
If the GV-NET/IO Card is listed as Prolific USB-to-Serial Comm Port under Windows
Device Manager, GV-System version 8.2 or above is required. If the GV-NET/IO Card is
listed as XR21B1411 USB UART under Windows Device Manager, GV-System version
8.5.7.0 or above is required.
To see how to check the device name under Windows Device Manager, refer to Installing
USB Driver later in this Installation Guide.
Packing List
1. GV-NET/IO Card x 1
2. 20-Pin Ribbon Cable with 4 Connectors x1
3. RJ-11 to DB9 Cable x 1
4. RJ-11 to USB Cable x 1
5. 3-Pin Internal USB Cable x 1
6. 4-Pin to 4-Pin Mini Power Cable x 1
7. Installation Guide x 1
8. Software DVD x 1
Probleemoplossing GeoVision GV-NET IO CARD V3.2
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Meerkleurig |
| Stroom: | 3 A |
| Soort serieële aansluiting: | RJ-11, RS-422, RS-485 |
| DC voltage input: | 9 - 30 V |
| Certificering: | CE. FC |
| Relatieve luchtvochtigheid: | 5 - 95 procent |
| Verbinding met pc: | Ja |
| Aantal kanalen: | 8 kanalen |
| Bedrijfstemperatuur (T-T): | 0 - 50 °C |
| Netspanning, in bedrijf: | 250 V |
| Signaal directie: | Invoer/uitvoer |
| Kanaal type: | Relay-kanaal |
