Pagina 1/4
Grid
L1
L2
L3
N
SDM630MCT ETL is a multi-functional din-rail meter designed for accurate measurement an d display of parameters i n 3P3W/3P4W power
grid systems, such as voltage, current, power, frequency, active power, reactiv e power, posi tive energy, reverse energy, total harmonics,
etc. It is an ideal choice for real-time power monitoring, featuring a wide range of functions and applications with high stability over
extended service life. The meter works with an external current transformer and can be applied in both high and low voltage power grid. It
comes with an RS485 communication interface, which supports a maximum baud rate of 38400 bps and enables remote communication.
TPM-CT-E-US (SDM630MCT ETL) Three-phase
Smart Meter Quick Guide
General Specifications
Rated voltage
3×277/480Vac
Rated frequency
50/60Hz
L-N voltage r ange
100 ~ 277Vac
L-L voltage range
100 ~ 480Vac
Auxiliary p ower voltage range
100 -277V
AC withstand voltage
4KV for 1min
Input current range
1A or 5A
Short-term overcurrent
20*IMAX for 0.5s
Max. Reading
9999999.9kWh/kVArh
Accuracy
Active powe r
1% of range maximum
Reactive po wer
±1% of range maximum
Environment
Regulated working temperature
range
- ℃～+ ℃25 55
Limited working tempe rature range
- ℃～ ℃40 +70
Relative hu midity annual average
≤90％
Installation category
CAT III
Degree of pol lution
RoHS compliant
Communica tion
Communica tion
RS485 output for Modbus RTU
Baud rate
9600bps (default)
Pulse
3200imp/kWh
Mechanics
Outline dimensions
3.72x2.83x2.56inch (LxWxH )
Din rail dimensions
DIN rail 1.38inch
Protection level
IP51 (indoor)
Item
Quantity
Description
A
1
Three-phase meter
B
1
Quick Insta llation Guide
C
1
RS485 cable (standard length: 15m)
D
3
Current Transformer
1
1
1
11.
.
.
..
Overview
2
2
2
22.
.
.
..
Technical Parameters
3
3
3
33.
.
.
..
Unpacking
Quick
inst
allation
man
ual
A B C D
4
4
4
44.
.
.
..
Dimensions (Unit: inch)
5
5
5
55.
.
.
..
Installation
1. The Growatt Stora ge Inverter and the Hybrid Inverter are hereinafter referred to as "the Storage/Hybrid Inverter".
2. The grid is on the right side and the c urrent flows from P1 to P2 (from the grid to the load).
Note:
Storage/
Hybrid
Inverter Grid
L1
L2
L3
N
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15 16 17 18 19 20
L N L N
Vol ta ge i np ut s
So Cu rr en t inpu tsRS 48 5
RS485-A
RS485-B
S2 S 1 S2 S1
3P3W
PE
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15 16 17 18 19 20
L N LN
Vol ta ge i np ut s
So Cu rr en t inpu tsRS 48 5
RS485-A
RS485-B
S2 S 1 S2 S1 S2 S1
3P4W
PE
Storage/
Hybrid
Inverter
1.38
1.38
3.72
2.8 3
2.56
P2 P1 P2 P1
