KWIK HUS-EZ 5/8
Hilti KWIK HUS-EZ 5/8 Handleiding
Hier is de Hilti KWIK HUS-EZ 5/8 (Niet gecategoriseerd) gebruikershandleiding. 1 pagina's in taal met een gewicht van 192,847.0 Mb. Als u geen antwoorden op uw probleem kunt vinden Vraag het onze community.
Pagina 1/1

h
nom
< 5"
h
nom
≥ 5"
Nuron SIW 4-22
Nuron SIW 6-22
Nuron SIW 8-22
CPC SIW 22T/18T-A
CPC SIW 9-A22/A18
85 ft-lb 85 ft-lb 38 ft-lb
90°
d
0
= ⌀ ⅝"
90°
d
0
= ⌀ ⅝"
TE-CD
TE-YD
WS
₁₅
∕₁₆
KH-EZ
⅝"
h
1
*
h
nom1
= 3.25"
h
nom2
= 4"
h
nom3
= 5"
h
nom4
= 6"
t
x1 max
t
x2 max
t
x3 max
t
x4 max
⅝" × 3½" 3⅞" – t
x
¼" – – –
⅝" × 4" 4⅜" – t
x
¾" – – –
⅝" × 4½" 4⅞" – t
x
1¼" ½" – –
⅝" × 5½" 5⅞" – t
x
2¼" 1" ½" –
⅝" × 6½" 6⅞" – t
x
3¼" 2½" 1½" ½"
⅝" × 8" 8⅜" – t
x
4¾" 4" 3" 2"
1a
2.1
2.2
31b
*For non-hole cleaning installation (step 1a), make sure to drill deep enough to achieve h
1
,
taking into account the depth of debris remaining in the hole.
d
f
t
fix
⅜"
h
1
h
nom
d
f
= ¾" …⌀
13
⁄
16
"
423832-03.2024
KWIK HUS-EZ ⅝"
