H BD3PR2 True Day/Night Indoor/Outdoor IR
Bullet IP Camera Regulatory Statements
Information to the User: This has equipment been and tested found to comply with the limits afor
Class B digital device, pursuant to part 15 of the Rules. FCC These limits are designed to provide
reasonable against protection harmful interference a in residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that a particular interference will not occur in installation.
Quick Installation Guide
Document 800 2123 10/2015- 3 — A– V1 Rev
Thank you for purchasing a HBD3PR2 c . amera
Follow the
instructions in this guide and to install
log to
your camera. For instructions on
configuring the
camera, refer to the Performance
Series IP
Cameras User Guide on the software
and
documentation CD that came with your
camera. If
you require additional assistance,
please call the
number shown below.
If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment is and off on, the user encouraged to try to correct the
interference by one or more of the following measures:
•
•
•
Reorient or relocate the receiving antenna.
Increase the the separation between equipment and receiver.
Connect the equipment into an outlet a that on circuit different from to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
Cautions and Warnings
•
Note Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
This B Class digital apparatus complies Canadian with ICES- 003.
Cet appareil numérique de la B à Classe est conforme la - Canada. norme NMB 003 du
Important Safeguards
WARNING
•
•
Read and keep these instructions.
Do not aim the camera toward a bright light source for extended periods to prevent damage to
the imager. Avoid operating the unit under or close to unstable light sources (may cause
flickering), or close to fluorescent lamps or objects reflecting light.
Do not touch the camera lens.
Do not drop the camera or subject it to physical shock.
Do not use a strong or abrasive detergent when cleaning the camera.
Avoid operating or storing the unit in extremely humid, dusty, hot/cold environments, where the
operating temperature is outside the recommended range of - 4°Fto 140°F (– 20°C to 60°C).
To ensure compliance with electrical safety standards this product is
intended for use with a Listed Power Adapter marked with “Limited Power Source”, “LPS”,
on the unit, output rated 12 V DC, minimum 0.33A, Tma=60Deg.C or from Power over
Ethernet (PoE) provided by Listed Information Technology Equipment meeting the IEEE
802.3af PoE standard. •
•
•
•
The Ethernet connection is not intended to be connected to exposed (outside plant)
networks. Do not connect two power sources to the camera at the same time.
CAUTION
Invisible LED radiation (850 nm). Avoid exposure to beam. Note
Do not apply power to the completing installation. camera before
Note
Confirm the installation surface can support at least three times the weight of the camera plus
the bracket.
Document 800 2123 /2015- 3 – A – V1 Rev 10 1
Probleemoplossing Honeywell HBD3PR2
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Wit |
| Gewicht: | 650 g |
| Diepte: | 214.8 mm |
| Hoogte: | 90.4 mm |
| Soort: | IP-beveiligingscamera |
| Internationale veiligheidscode (IP): | IP66 |
| Ondersteunde mobiele besturingssystemen: | Android, iOS |
| Maximale capaciteit van de geheugenkaart: | 128 GB |
| Vormfactor: | Rond |
| Automatisch scherpstellen: | Ja |
| Ondersteuning voor plaatsing: | Binnen & buiten |
| Connectiviteitstechnologie: | Bedraad |
| Ethernet LAN: | Ja |
| Montagewijze: | Muur |
| Ondersteunde video-modi: | 720p, 1080p |
| Maximum resolutie: | 2304 x 1296 Pixels |
| Totaal aantal megapixels: | 3 MP |
| Type stroombron: | Power over Ethernet (PoE) |
| Stroomuitvoer (volt): | 12 |
| Minimale belichting: | 0.1 Lux |
| Aantal cameras: | 1 |
| Geïntegreerde geheugenkaartlezer: | Ja |
| Compatibele geheugenkaarten: | MicroSDHC |
| Nachtvisie: | Ja |
| LED-type: | IR |
| HTTPS-encryptie: | Ja |
| Zoomcapaciteit: | Ja |
| Aantal Ethernet LAN (RJ-45)-poorten: | 1 |
| Focus: | Gemotoriseerd |
| Brandpuntbereik: | 2.7 - 12 mm |
| Vermogensverbruik (max): | 8.5 W |
| Certificering: | FCC |
| Volledige HD: | Ja |
| Omvang optische sensor: | 1/3 " |
| Type beeldsensor: | CMOS |
| Camera sluitertijd: | 1/100000 s s |
| Witbalans: | Auto, Manual |
| Ondersteunde grafische resoluties: | 352 x 240,352 x 288,704 x 480,704 x 576,1280 x 720 (HD 720),1920 x 1080 (HD 1080) |
| Plug and play: | Ja |
| Bekabelingstechnologie: | 10/100Base-T(X) |
| Netwerkstandaard: | IEEE 802.3af |
| Ondersteunde beveiligingsalgoritmen: | 802.1x RADIUS |
| Aantal gebruikers: | 20 gebruiker(s) |
| Veiligheidsfunties: | Waterbestendig |
| Maximaal 30 frames per seconde: | 30 fps |
| Op afstand bedienbaar: | Ja |
| Progressive scan: | Ja |
| Quality of Service (QoS): | Ja |
| Power over Ethernet (PoE): | Ja |
| Type sterkteregeling: | Automatisch/handmatig |
| Dag/nacht modus: | Ja |
| Maximum aperture number: | 1.4 |
| Bewegingssensor: | Ja |
| Nachtkijker afstand: | 30 m |
| Achtergrondverlichting compensatie: | Ja |
| Aantal effectieve pixels (H x V): | 2304 x 1296 Pixels |
| Highlight Compensation (HLC) (compensatie voor sterke belichting): | Ja |
| Bedrijfstemperatuur (T-T): | -30 - 60 °C |
| Relatieve vochtigheid in bedrijf (V-V): | 10 - 100 procent |
| Kijkhoek lens, horizontaal: | 86 ° |
| Digital Wide Dynamic Range (DWDR): | Ja |
| Smart IR: | Ja |
| 3D-geluidsreductie: | Ja |
