Ideal for all residential applications, Honeywell’s IS335 Motion
Detector delivers exceptional value and performance while
reducing false alarms. Installations are quick and easy—
saving you time and money. The IS335 features selectable
pet immunity for animals weighing up to 80 lbs, an
always-enabled LED, 40 x 56 range and a style that
blends with any décor.
• Sealed Optics
The sealed optical chamber prevents
drafts and insects from affecting
the detector.
• Uniform Sensitivity Optics
Whether an intruder is directly in front
of the sensor or at the edge of a
protected area, the custom designed
Fresnel lens provides a consistent
level of detection—delivering optimal
performance no matter what the
distance. Shorter precision focal lengths
mean superior optics and detection.
• Wall-to-Wall Coverage
Wide and long detection coverage for
coverage range protection that exceeds
similar products in the market.
• Superior Detection and
False Alarm Immunity
The IS335 motion detector provides
superior protection against false alarms
without sacrificing catch performance.
• Pet-friendly Selectivity
Installers can turn pet immunity on or
off simply by setting a jumper. When
pet immunity is enabled, the detector
can distinguish between signals
caused by humans while ignoring pets
up to 80 lbs.
• PIR White Light Immunity
A patented black bug guard reduces
false alarms by providing 2,000 lux of
white light immunity. This helps reduce
false alarm problems caused by lights,
flashlights or reflective objects.
• Flexible Mountings
The IS335 motion detector mounts on
walls or in corners, with heights from
7 ft - 9 ft (2.1 m - 2.7 m).
FEATURES
IS335
WIRED PIR MOTION DETECTOR
Specifications IS335 (PIR)
Range 40' x 56'
Power 9.0 - 15 VDC; 7 mA typical, 12 mA maximum; AC Ripple: 3 V peak-to-peak at nominal 12 VDC
Alarm Relay Energized Form A; 90 mA, 15 VDC, 22 Ohms resistance maximum. Alarm Relay Duration: 3 seconds
RFI Immunity 20V/m 10-1000 MHz, 15V/m 1000-2700 MHz
PIR White Light Immunity 2,000 Lux typical
Operating Temperature 14°F to 131°F/-10°C to 55°C
Relative Humidity 5 to 93%; non-condensing
Temperature Compensation Advanced Dual Slope
Dimensions 3.39 H x 2.24 W x 1.71 D/8.6 cm H x 5.7 cm W x 4.35 cm D" " "
Weight 2.15 oz/61 g (net weight)
Pet Immunity ≤ 80 lbs./36kg
Probleemoplossing Honeywell IS335T
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Wit |
| Breedte: | 57 mm |
| Diepte: | 43.5 mm |
| Hoogte: | 86 mm |
| Gebruikershandleiding: | Ja |
| LED-indicatoren: | Ja |
| Plaatsing: | Binnen |
| Connectiviteitstechnologie: | Bedraad |
| Montagewijze: | Muur |
| Type stroombron: | DC |
| Type beeldsensor: | Passieve infraroodsensor (PIR) |
| Ingangsspanning: | 9 - 15 V |
| Frequentie: | 1000 MHz |
| Stroomverbruik: | 90 mA |
| Bedrijfstemperatuur (T-T): | -10 - 55 °C |
| Relatieve vochtigheid in bedrijf (V-V): | 5 - 93 procent |
| Installatie hoogte (min): | 2.1 m |
| Installatie hoogte (max): | 2.7 m |
| Lichtgevoeligheid: | 2000 Lux |
| Statische stroom: | 7 mA |
| Huisdierimmuniteit (max): | 36 kg |
