Pagina 1/4
EN
User Guide
THANK YOU FOR PURCHASING A PRODUCTHOTPOINT .
To receive more comprehensive assistance, register the
appliance on www.hotpoint.eu/register
Before using the appliance carefully read the Health and Safety guide.
Before using the machine, it is imperative that the transport bolts are removed. For more
detailed instructions on how to remove them, see the Installation Guide.
CONTROL PANEL
WASH CYCLE TABLE
PRODUCT DESCRIPTION
1.
3.
2.
5.
4.
7.
6.
8.
1. Top
2. Detergent dispenser drawer
3. Control panel
4. Handle
5. Porthole door
6. Drain pump (behind the plinth)
7. Plinth (removable)
8. Adjustable feet (2)
1. ON/OFF button
2. DRY ONLY button and indicator light
3. KEY LOCK button and indicator light
4. EXTRA TOUCH button
5. EXTRA TOUCH indicator lights
6. START/PAUSE button and indicator light
7. DELAY button and indicator light
8. buttonDRYING LEVEL
9. SPIN button
10. TEMPERATURE button
11. WASH CYCLE SELECTOR KNOB
DETERGENT DISPENSER DRAWER
Compartment *:
Do not insert detergent in this compartment.
Compartment 1: Washing detergent (powder
or liquid)
If liquid detergent is used, the removable plastic
partition (supplied) should be used for proper A
dosage.
If powder detergent is used, place the partition
into slot .B
Compartment 2: Additives (fabric softeners, etc.)
The fabric softener must not exceed the “MAX” level.
! Use powder detergent for white cotton garments, for pre-washing, and
for washing at temperatures over 60°C.
! Follow the instructions given on the detergent packaging.
1
2
A
B
*
1
11
2
DISPLAY
5
678
910
4
3
For all testing institutes:
2) Long cotton cycle: set programme COTTON at temperature 40°C.
3) Long synthetics cycle: set cycle at a temperature of 40°C.SYNTHETICS
* By selecting the cycle and excluding the spin cycle, the washer-dryer will drain only.
** The duration of the wash cycles can be checked on the display.
*** After programme end and spinning with maximum selectable spin speed, in default
programme setting.
**** The display will show the suggested spin speed as default value.
The cycle duration indicated on the display or instruction manual is an estimate based on
standard conditions. The actual duration may vary in relation to several factors, such as the
temperature and pressure of the incoming water, ambient temperature, amount of detergent,
load quantity and type, load balancing and any additional options selected. The values given
for programmes other than the Eco 40-60 programme are indicative only.
1) Eco 40 -60 (Wash) - Test wash cycle in compliance with EU Ecodesign regulation
2019/2014. The most ecient programme in terms of energy and water consumption for
washing normally soiled cotton laundry.
Note: spin speed values shown on the display can slightly diers from the values stated in the table.
4) Eco 40-60 (Wash & Dry)-
Test
wash and
drying cycle in compliance with EU Ecodesign
regulation
2019/2014
. To access “wash and dry” cycle select “Eco 40-60” wash programme
and set “Drying Level” to
“
A3
”.
The most ecient programme in terms of energy and water
consumption for washing and drying normally soiled cotton laundry. At the end of cycle the
garments can be immediately stored to the cupboard.
Maximum washing load 11 kg. Maximum drying load 7 kg.
Power input in o mode 0.5 W / in left-on mode 8 W Detergents and
Additives Recommended
detergent
Residual
dampness %
(***)
Energy
consumption
kWh
Total water lt
Laundry
temperature °C
Wash cycle Temperature Max.
spin
speed
(rpm)
Max.
load for
washing
(kg)
Duration
(h : m)
Drying
Max.
load for
drying
(kg)
Wash Fabric
softener
Powder
Liquid
Setting Range 1 2
Wash & Dry Mixed 30 °C - 30 °C 1200 3.5 ** 3.5 –– – – –
Wash & Dry XL Bed & Bath 60 °C - 60 °C 1600 7.0 ** 7.0 –– – – –
Cotton (2) 40 °C - 60 °C 1600 11.0 3:55 7.0 49 1.14 107 45
Synthetics (3) 40 °C - 60 °C 1200 5.5 2:55 5.5 35 0.83 80 43
Wool 40 °C - 40 °C 800 2.5 ** 2.5 –– – – –
Delicates 30 °C - 30 °C 600 ( ) 1.0 ****** 1.0 –– – – –
Anti Allergy 60°C 1600 5.5 **40 °C - 60 °C 5.5 – – – –
Anti Stain 40 °C - 40 °C 1600 11.0 ** 7.0 –– – – –
Steam Refresh – – – 2.0 ** – – – – – – – – – –
Spin & Drain *– – 1600 11.0 ** 7.0 – – – – – – – –
Rinse & Spin – – 1600 11.0 ** 7.0 – – – – – – –
Wash 20°C 20 °C - 20 °C 1600 11.0 1:50 – – –54,5 0.20 95 22
Eco 40-60 (1)
(Wash) 40 °C 40°C
1551 11.0 4:00
7.0
44 0.97 65 30
1551 5.5 3:00 44 0.85 64 28
1551 3 2:40 44 0.49 44 22
Intense 60-90°C 60 °C - 90 °C 1600 11.0 2:40 7.0 54 1.90 100 55
Rapid Wash 30 °C - 30 °C 1200 ( ) 5.5 0:30 – –**** –71 0.21 50 27
Wash & Dry XS Rapid 30 °C 1600 1.0 **30 °C 1.0 –– – – –
Required dosage Optional dosage
Eco 40-60 (4)
(Wash & Dry) 40 °C 40 °C 1551 7.0 9:50 7.0 0 5.10 75 33
1551 3.5 6:00 3.5 0 2.70 53 33
Probleemoplossing Hotpoint NDB 11724 W UK
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Apparaatplaatsing: | Vrijstaand |
| Soort bediening: | Buttons, Rotary, Touch |
| Kleur van het product: | Wit |
| Deurscharnieren: | Links |
| Ingebouwd display: | Ja |
| Gewicht: | 73400 g |
| Breedte: | 595 mm |
| Diepte: | 605 mm |
| Hoogte: | 850 mm |
| Netbelasting: | 1850 W |
| Type lader: | Voorbelading |
| Deurkleur: | Wit |
| Snoerlengte: | 1.2 m |
| Trommelinhoud: | 71 l |
| Uitgestelde start timer: | Ja |
| Resterende tijd indicatie: | Ja |
| Anti-kreuk functie: | Nee |
| Energieverbruik wassen: | 0.701 kWu |
| Centrifuge-droger klasse: | A |
| Geluidsniveau (wassen): | - dB |
| Maximale centrifugesnelheid: | 1600 RPM |
| Stroom: | 13 A |
| Geluidsemissieklasse: | C |
| Inverter technologie: | Ja |
| Droogcapciteit: | 7 kg |
| Functie voor kleding toevoegen (pauze): | Ja |
| Geluidsniveau bij centrifugeren: | 80 dB |
| Geluidsniveau (drogen): | - dB |
| Energiegebruik bij wassen & drogen: | 0.414 kWu |
| Waterverbruik wassen & drogen: | 66 l |
| Water verbruik wassen: | 54 l |
| Aan-/uitknop: | Ja |
| Verstelbare voeten: | Ja |
| Diepte wanneer de deur open is: | 1045 mm |
| Stroomverbruik (in standby): | 0.5 W |
| Energie-efficiëntieklasse (wassen): | C |
| Energie-efficiëntieklasse (wassen en drogen): | E |
| Energieverbruik per 100 cycli (wassen): | 70 kWu |
| Energieverbruik per 100 cycli (wassen en drogen): | 414 kWu |
| Stroomverbruik (indien uit): | 0.5 W |
| Programmaduur wassen & drogen: | 590 min |
| Duur wascyclus: | 240 min |
| Diepte met deur gesloten: | 639 mm |
| Nominale capaciteit (wassen): | 11 kg |
| AC-ingangsspanning: | 220-240 V |
| AC-ingangsfrequentie: | 50 Hz |
| Type beeldscherm: | LCD |
| Energie-efficiëntieschaal: | A tot G |
| Wasprogramma's: | Cotton, Cottons 40°C, Cottons 60°C, Delicate/silk, Down wear/duvet, Hygiene air refresh, Hygiene/anti-allergy, Rinse & spin, Spin/drain, Steam, Synthetics, Wool |
| Droogprogramma's: | Cotton, Delicate/silk, Down wear/duvet, Hygiene/anti-allergy, Hygienic freshen-up, Steam, Synthetics, Wool |
