GB
Quick Guide
THANK YOU FOR PURCHASING A HOTPOINT PRODUCT.
To receive more comprehensive assistance, register the
appliance on
www.hotpoint.eu/register
Before using the appliance carefully read the Health and Safety guide.
Before using the machine, it is imperative that the transport bolts are removed. For more
detailed instructions on how to remove them, see the Installation Guide.
CONTROL PANEL
WASH CYCLE TABLE
For all testing institutes:
2) Long cotton cycle: set wash cycle Cotton with a temperature of 40°C.
3) Long synthetics cycle: set wash cycle with a temperature of 40°C.Synthetics
4) The display will show the suggested spin speed as default value.
* By selecting the cycle and excluding the spin cycle, the washing machine will Spin & Drain
drain only.
** The duration of the wash cycles can be checked on the display.
*** For Prewash press the “Temp.” button until the symbol lights up (only 90°).
****
After programme end and spinning with maximum selectable spin speed, in default
programme setting.
The cycle duration indicated on the display or instruction manual is an estimate based on
standard conditions. The actual duration may vary in relation to several factors, such as the
temperature and pressure of the incoming water, ambient temperature, amount of detergent,
load quantity and type, load balancing and any additional options selected.The values given
for programmes other than the Eco 40-60 programme are indicative only.
1) Eco 40-60 - Test wash cycle in compliance with EU Ecodesign regulation 2019/2014. The
most ecient programme in terms of energy and water consumption for washing normally
soiled cotton laundry.
Note: spin speed values shown on the display can slightly diers from the values stated in
the table.
PRODUCT DESCRIPTION
1.
3.
2.
5.
4.
7.
6.
8.
1. Top
2. Detergent dispenser drawer
3. Control panel
4. Handle
5. Porthole door
6. Drain pump (behind the plinth)
7. Plinth (removable)
8. Adjustable feet (2)
Maximum load 10 kg
Power input in o mode 0.5 W / in left-on mode 8 W Add
Gar-
ments
( )
Detergents and
Additives
Recommended
detergent
Residual
dampness % (****)
Energy
consumption kWh
Total water lt
Laundry
temperature °C
Wash cycle
Temperature Max.
spin speed
(rpm)
Max.
load
(kg)
Dura-
tion
(h : m)
Pre-
wash Wash Fabric
softener Pow-
der Liquid
Setting Range 1 2 3
Eco 40-60 (1) 40 °C 40°C
1351 10,0 3:55 – – 53 0,82 69 31
1351 5,0 3:00 – – 53 0,55 56 29
1351 2,5 2:30 – – 53 0,29 38 25
Cotton (2) 40°C - 60°C 1400 10,0 3:55 – – 49 1,14 107 45
Synthetics (3) 40°C - 60°C 1200 5,5 2:55 – – 35 0,83 80 43
Mixed 40°C - 40°C 1400 10,0 ** – –– – – –
Delicates 40°C - 40°C 1000 5,5 ** – –– – – –
White 40°C - 90°C 1400 10,0 2:05 (***) 54 0,90 100 42
Anti Stain 40° 40°C - 40°C 1000 5,5 ** – – – – –
Rapid 30 min 30°C - 30°C 1200 (4) 5,5 0:30 – –71 0,21 50 27
Spin & Drain * – – 1400 10,0 ** – – – – – – – – – – –
Rinse & Spin – – 1400 10,0 ** – – – – – – – – – –
Steam Refresh – – – 2,0 ** – – – – – – – – – – –
20°C 20 °C - 20 °C 1400 10,0 1:50 – – –55 0,20 95 22
Wool 40°C - 40°C 800 2,5 ** – – –– – – –
Anti Allergy 60°C 40°C -
60°C 1400 5,5 ** – – – – – –
Bed & Bath 60°C - 60°C 1400 10,0 ** – – – – –
Dosing required Dosing optional
DETERGENT DISPENSER DRAWER
compartment 1: Pre-wash detergent
(powder)
compartment 2: Detergent for the wash
cycle (powder or liquid)
If liquid detergent is used, it is recommended
that the removable plastic partition A
(supplied) be used for proper dosage.
If powder detergent is used, place the partition
into slot B.
compartment 3: Additives (fabric softeners,
etc.)
The fabric softener should not overow the grid.
! Use powder detergent for white cotton garments, for pre-washing, and
for washing at temperatures over 60°C.
! Follow the instructions given on the detergent packaging.
1
2
3
A
B
1. STEAM HYGIENE / MUTE button
2. FINAL CARE / KEY LOCK button
3. ON/OFF button
4. ACTIVE CARE button and indicator light
5. START/PAUSE button
6. RAPID / GREEN button
7. SPIN button
8. START DELAY button
9. TEMPERATURE button
10. WASH CYCLE SELECTOR KNOB
1 2
4
56789
3
10
DISPLAY
Probleemoplossing Hotpoint NM11 1046 WD A UK N
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Apparaatplaatsing: | Vrijstaand |
| Soort bediening: | Rotary, Touch |
| Kleur van het product: | Wit |
| Deurscharnieren: | Links |
| Ingebouwd display: | Ja |
| Timer: | Ja |
| Gewicht: | 75900 g |
| Breedte: | 595 mm |
| Diepte: | 605 mm |
| Hoogte: | 850 mm |
| Netbelasting: | 1850 W |
| Type lader: | Voorbelading |
| Deurkleur: | Chroom |
| Snoerlengte: | 1.2 m |
| Trommelinhoud: | 71 l |
| Resterende tijd indicatie: | Ja |
| Wi-Fi-besturing: | Nee |
| Geluidsniveau: | 76 dB |
| Energie-efficiëntieklasse: | A |
| Gewicht verpakking: | 77500 g |
| Breedte verpakking: | 645 mm |
| Diepte verpakking: | 605 mm |
| Hoogte verpakking: | 590 mm |
| Energie-efficiëntieklasse (oud): | A+++ |
| Geschikt voor paneelaanpassing: | Nee |
| Energieverbruik wassen: | 0.966 kWu |
| Waterconsumptie per cyclus: | 52 l |
| Wasklasse: | A |
| Jaarlijkse energieverbruik wassen: | 190 kWu |
| Centrifuge-droger klasse: | B |
| Geluidsniveau (wassen): | 76 dB |
| Sopschuimbewaking: | Ja |
| Onbalanscontrolesysteem: | Ja |
| Aanpasbare centrifugesnelheid: | Ja |
| Maximale centrifugesnelheid: | 1400 RPM |
| Stroom: | 13 A |
| Zelfreinigend: | Ja |
| Geluidsemissieklasse: | B |
| Functie voor kleding toevoegen (pauze): | Ja |
| Geluidsniveau bij centrifugeren: | 76 dB |
| Jaarlijks waterverbruik wassen: | 12810 l |
| Near Field Communication (NFC): | Nee |
| Restvochtpercentage: | 53 procent |
| Cyclustijd (max): | 235 min |
| Tijdsduur tot uitschakelen: | 30 min |
| Aantal wasprogramma's: | 15 |
| Duur cyclus (snelwas programma): | 30 min |
| Energieverbruik per 100 cycli: | 51 kWu |
| Aan-/uitknop: | Ja |
| Verstelbare voeten: | Ja |
| Kuip materiaal: | Kunststof |
| Bescherming tegen overstromen: | Ja |
| Half-geladen: | Ja |
| Instelbare temperatuur: | Ja |
| Stroomverbruik (ingeschakeld houden): | 8 W |
| Stroomverbruik (indien uit): | 0.5 W |
| Spoelstop: | Nee |
| LED programmavoortgangsindicator: | Ja |
| Spoelen Plus functie: | Ja |
| Display verlichting: | Ja |
| Kleur van de verlichting: | Geel |
| Uitgave lade type: | 3-weg |
| Nominale capaciteit: | 10 kg |
| AC-ingangsspanning: | 220 - 240 V |
| AC-ingangsfrequentie: | 50 Hz |
| Energie-efficiëntieschaal: | A tot F |
| Wasprogramma's: | Bedding, Hygiene/anti-allergy, Blouse/shirt, Cotton, Eco, Wool, Mix, Quick, Steam, Synthetics, White, Delicate/silk |
