Pagina 1/4
GB
Quick Guide
THANK YOU FOR PURCHASING A HOTPOINT PRODUCT.
To receive more comprehensive assistance, register the
appliance on
www.hotpoint.eu/register
Before using the appliance carefully read the Health and Safety guide.
Before using the machine, it is imperative that the transport bolts are removed. For more
detailed instructions on how to remove them, see the Installation Guide.
CONTROL PANEL
WASH CYCLE TABLE
* By selecting the cycle and excluding the spin cycle, the washing machine will Spin & Drain
drain only.
** The duration of the wash cycles can be checked on the display.
***
After programme end and spinning with maximum selectable spin speed, in default
programme setting.
**** The display will show the suggested spin speed as default value.
! If “Steam Hygiene” option is set, the duration of the wash cycles will increase.
The cycle duration indicated on the display or instruction manual is an estimate based on
standard conditions. The actual duration may vary in relation to several factors, such as the
temperature and pressure of the incoming water, ambient temperature, amount of detergent,
load quantity and type, load balancing and any additional options selected.The values given
for programmes other than the Eco 40-60 programme are indicative only.
1) Eco 40-60 - Test wash cycle in compliance with EU Ecodesign regulation 2019/2014. The
most ecient programme in terms of energy and water consumption for washing normally
soiled cotton laundry.
Note: spin speed values shown on the display can slightly diers from the values stated in
the table.
For all testing institutes:
2) Long cotton cycle: set programme at temperature 40°C. Cotton
3) Long synthetics cycle: set cycle at a temperature of 40°C.Synthetics
PRODUCT DESCRIPTION
1.
3.
2.
5.
4.
7.
6.
8.
1. Top
2. Detergent dispenser drawer
3. Control panel
4. Handle
5. Porthole door
6. Drain pump (behind the plinth)
7. Plinth (removable)
8. Adjustable feet (2)
1. ON/OFF button
2. KEY LOCK button
3. EXTRA TOUCH button
4. EXTRA TOUCH indicator lights
5. START/PAUSE button and indicator light
6. OPTION button and indicator light
7. DELAY START button
8. SPIN button
9. TEMPERATURE button
10. WASH CYCLE SELECTOR KNOB
Maximum load
7 kg
Power input in o mode 0.5 W / in left-on mode 8 W
Detergents and
Additives
Recommended
detergent
Residual
dampness %
(***)
Energy
consumption
kWh
Total water lt
Laundry
temperature
°C
Wash cycle Temperature Maximum
spin
(r.p.m.)
Max.
load
(kg)
Duration
(h : m)
Wash Fabric
softener Powder Liquid
Setting Range 2 3
Mixed 40°C - 40°C 1400 7,0 ** –––––
Eco 40-60 (1) 40 °C 40°C
1351 7,0 3:25 53 0,95 48 43
1351 3,5 2:42 53 0,62 45 33
1351 2,0 2:20 53 0,38 39 25
Cotton (2) 40°C - 60°C 1400 7,0 3:40 50 0,98 75 45
Synthetics (3) 40°C - 60°C 1200 4,0 2:55 35 0,86 60 43
Delicates 40°C - 40°C 1000 4,0 ** –––––
Wool 40°C - 40°C 800 1,5 ** –––––
Anti Allergy 60°C 40°C - 60°C 1400 4,0 ** ––––
Spin & Drain * – – 1400 7,0 ** – – – – – – – –
Rinse & Spin – – 1400 7,0 ** – ––––––
Baby 40°C - 40°C 1200 (****) 3,0 ** –––––
20°C 20 °C - 20 °C 1400 7,0 1:50 –52 0,16 64 22
Duvet 30°C - 30°C 1000 3,0 ** –––––
White 40°C - 90°C 1400 7,0 1:40 – 52,1 0,65 66 42
30 min 30°C - 30°C 1200 (****) 3,5 0:30 –73 0,19 31 27
Full Load 45 min 40°C - 40°C 1200 7,0 ** –––––
Anti Stain 40° 40°C - 40°C 1400 7,0 ** –––––
Required dosage Optional dosage
DETERGENT DISPENSER DRAWER
Compartment *:
Do not insert detergent in this compartment.
Compartment 1: Washing detergent (powder
or liquid)
If liquid detergent is used, the removable plastic
partition (supplied) should be used for proper A
dosage.
If powder detergent is used, place the partition
into slot .B
Compartment 2: Additives (fabric softeners, etc.)
The fabric softener must not exceed the “MAX” level.
! Use powder detergent for white cotton garments, for pre-washing, and
for washing at temperatures over 60°C.
! Follow the instructions given on the detergent packaging.
1
2
A
B
*
1
10
2
DISPLAY
4
567
89
3
Probleemoplossing Hotpoint NSWM 743U GG UK N
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Apparaatplaatsing: | Vrijstaand |
| Soort bediening: | Buttons, Rotary |
| Kleur van het product: | Grafiet |
| Ingebouwd display: | Ja |
| Timer: | Ja |
| Breedte: | 595 mm |
| Diepte: | 522 mm |
| Hoogte: | 850 mm |
| Netbelasting: | 1850 W |
| Type lader: | Voorbelading |
| Materiaal trommel: | Roestvrijstaal |
| Snoerlengte: | 1.2 m |
| Trommelinhoud: | 46 l |
| Uitgestelde start timer: | Ja |
| Startvertraging: | 4 uur |
| Resterende tijd indicatie: | Ja |
| Kinderslot: | Ja |
| Wi-Fi-besturing: | Nee |
| Geluidsniveau: | 83 dB |
| Anti-kreuk functie: | Ja |
| Energie-efficiëntieklasse: | D |
| Breedte verpakking: | 645 mm |
| Diepte verpakking: | 595 mm |
| Hoogte verpakking: | 890 mm |
| Waterconsumptie per cyclus: | 45 l |
| Centrifuge-droger klasse: | B |
| Geluidsniveau (wassen): | - dB |
| Sopschuimbewaking: | Nee |
| Aanpasbare centrifugesnelheid: | Ja |
| Maximale centrifugesnelheid: | 1400 RPM |
| Deur open alarm: | Ja |
| Bluetooth: | Nee |
| Stroom: | 10 A |
| Zelfreinigend: | Nee |
| Geluidsemissieklasse: | D |
| Functie voor kleding toevoegen (pauze): | Nee |
| Geluidsniveau bij centrifugeren: | - dB |
| Restvochtpercentage: | 53 procent |
| Aantal wasprogramma's: | 15 |
| Energieverbruik per 100 cycli: | 78 kWu |
| Land van herkomst: | Italië |
| Bescherming tegen overstromen: | Ja |
| AquaStop-functie: | Nee |
| Half-geladen: | Nee |
| Instelbare temperatuur: | Ja |
| Stroomverbruik (in standby): | 0.5 W |
| Watertoevoer: | Koud |
| Stroomverbruik (indien uit): | 0.5 W |
| Spoelstop: | Nee |
| Gesproken navigatie-instructies: | Nee |
| Easy Iron-functie: | Nee |
| Vlekkenverwijderaarsoptie: | Ja |
| Energieverbruik (uit): | 0.5 kWu |
| Nominale capaciteit: | 7 kg |
| AC-ingangsspanning: | 220 - 240 V |
| Type beeldscherm: | LED |
| Energie-efficiëntieschaal: | A tot G |
| Wasprogramma's: | Bedding, Hygiene/anti-allergy, Baby care, Cotton, Eco, Wool, Steam, Synthetics, White |
