Aruba 340 Series Campus Access Point
Installation Guide
Installation Guide | January 2018 1
Aruba 340 Series Campus Access Point 340 Series (AP-344 and AP-345) are high-performance dual-radio wireless devices.
These access points (AP) provide secure wireless connectivity for 2.4GHz 802.11 b/g/n and 5GHz 802.11a/n/ac Wi-Fi
networks. The optional dual-5GHz radio mode allows both radios to operate in the 5GHz radio mode simultaneously,
doubling the 5GHz capacity of the access point. The 340 Series can be deployed in either a controller-based (ArubaOS) or
controllerless (InstantOS) network environment. Two wired Ethernet ports located on the back of this access point are
available to connect the access point to the wired infrastructure and to deliver power the device.
This access point can be attached to a standard flat 9/16" or 15/16” suspended ceiling rail using the mount adapters
provided. Other mounting options are supported by additional mount kits (sold separately).
Aruba 340 Series Campus Access Point 340 Series provide the following capabilities:
Wireless access
Wireless mesh
Air Monitor (AM)*
Spectrum Monitor (SM)*
Support for selected USB peripherals
Integrated Bluetooth Low Energy (BLE) radio
* Air Monitor and Spectrum Monitor features are not supported while this device operates in dual-5GHz mode.
Package Contents
The following materials are included with this product:
Aruba 340 Series Campus Access Point
9/16" and 15/16” ceiling rail mount adapters
Hardware Overview
The following sections describe the hardware components of the 340 Series access point.
Figure 1 Aruba AP-345 (front view)
Inform your supplier if there are any incorrect, missing, or damaged parts. If possible, retain the carton, including the
original packing materials. Use these materials to repack and return the unit to the supplier if needed.
