QuickSpecs
HPE ProLiant DL20 Gen10 Server
Overview
Page 1
HPE ProLiant DL20 Gen10 Server
The dense and compact HPE ProLiant DL20 Gen10 Server powered by Intel® Xeon® E Processor, Pentium and Core i3 processors
provides a unique blend of enterprise class capabilities & value. It offers outstanding configuration flexibility to cater to
a wide va
riety
of business requirements at an affordable price point.
Deploy this dense
platform for diverse workloads in space constrained
environments and maintain it with ease by automating the most essential server lifecycle management tasks with HPE iLO 5.
2 LFF Front View
1.
Access Panel
7.
Health LED
2.
Optical drive bay
8.
NIC Status LED
3.
Serial number/iLO information pull tab
9.
USB 3.0 Port
4.
Front Fan Assembly
10.
iLO Service Port (USB)
5.
System Power LED
11.
Two- bay LFF hot plug drive bays-
6.
UID LED
4 (+2) SFF Front View
1.
Access Panel
7.
Health LED
2.
2 SFF hot plug drive bays (optional)
8.
NIC Status LED
3.
Serial number/iLO information pull tab
9.
USB 3.0 Port
4.
Front Fan Assembly
10.
iLO Service Port (USB)
5.
System Power LED
11.
4 SFF hot plug drive bays
6.
UID LED
Probleemoplossing HP ProLiant DL20 Gen10
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Zwart |
| Breedte: | 434.6 mm |
| Diepte: | 382.2 mm |
| Hoogte: | 43.2 mm |
| Frequentie van processor: | 3.7 GHz |
| Processorfamilie: | Intel® Pentium® G |
| Processormodel: | G5400 |
| Aantal processorkernen: | 2 |
| Inclusief besturingssysteem: | Nee |
| Ethernet LAN: | Ja |
| Processor lithografie: | 14 nm |
| VGA (D-Sub)poort(en): | 1 |
| Aantal Ethernet LAN (RJ-45)-poorten: | 2 |
| Netvoeding: | 290 W |
| Intern geheugen: | 8 GB |
| Intern geheugentype: | DDR4-SDRAM |
| Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A: | 3 |
| Processor socket: | LGA 1151 (Socket H4) |
| Systeembus: | 8 GT/s |
| Processor aantal threads: | 4 |
| PCI Express slots versie: | 3.0 |
| Processor operating modes: | 64-bit |
| Processor cache: | 4 MB |
| Tjunction: | 100 °C |
| Bus type: | DMI3 |
| PCI Express configuraties: | 1x16,1x8+2x4,2x8 |
| Thermal Design Power (TDP): | 54 W |
| Codenaam processor: | Coffee Lake |
| Maximaal aantal PCI Express-lijnen: | 16 |
| Processor cache type: | Smart Cache |
| ECC ondersteund door processor: | Ja |
| Processorfabrikant: | Intel |
| Maximum intern geheugen: | 64 GB |
| Totale opslagcapaciteit: | 0 GB |
| Soort optische drive: | Nee |
| Ingebouwde grafische adapter: | Ja |
| On-board graphics adapter model: | Intel® UHD Graphics 610 |
| Basisfrequentie ingebouwde grafische adapter: | 350 MHz |
| Graphics on-board -adapter dynamische frequentie (max): | 1050 MHz |
| On-board grafische adapter ID: | 0x3E90/x93 |
| Maximaal geheugen ingebouwde grafische adapter: | 64 GB |
| On-board grafische adapter DirectX-versie: | 12.0 |
| On-board grafische adapter OpenGL versie: | 4.5 |
| Ondersteunde instructie sets: | SSE4.1,SSE4.2 |
| Intel® Hyper Threading Technology (Intel® HT Technology): | Ja |
| Intel® Turbo Boost Technology: | Nee |
| Intel® Quick Sync Video Technology: | Ja |
| Intel® InTru™ 3D Technology: | Ja |
| Intel® Clear Video HD Technology (Intel® CVT HD): | Ja |
| Intel® AES New Instructions (Intel® AES-NI): | Ja |
| Enhanced Intel SpeedStep Technology: | Ja |
| Execute Disable Bit: | Ja |
| Idle States: | Ja |
| Thermal Monitoring Technologies: | Ja |
| CPU configuratie (max): | 1 |
| Intel® Enhanced Halt State: | Ja |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel® CVT for MID): | Ja |
| Intel® VT-x with Extended Page Tables (EPT): | Ja |
| Ingebouwde opties beschikbaar: | Ja |
| Intel® Secure Key: | Ja |
| Intel® 64: | Ja |
| Intel® OS Guard: | Ja |
| Intel® Virtualization Technology for Directed I/O (VT-d): | Ja |
| Intel® Clear Video-technologie: | Ja |
| Intel® Software Guard Extensions (Intel® SGX): | Ja |
| Intel® Virtualization Technology (VT-x): | Ja |
| Verpakkingsgrootte processor: | 37.5 x 37.5 mm |
| Intel® Identity Protection Technology (Intel® IPT): | Ja |
| Versie Intel® Identity Protection Technology: | 1.00 |
| Versie Intel® Secure Key Technology: | 1.00 |
| ARK ID processor: | 129951 |
| Intel® Trusted Execution Technology: | Nee |
| Intel® TSX-NI: | Nee |
| Intel® Stable Image Platform Program (SIPP): | Nee |
| Versie Intel® Stable Image Platform Program (SIPP): | 0.00 |
| Versie Intel® TSX-NI: | 0.00 |
| Rack-montage: | Ja |
| Type behuizing: | Rack (1U) |
| Redundante voeding: | Nee |
| Maximaal intern geheugen ondersteund door processor: | 64 GB |
| Geheugentypen ondersteund door processor: | DDR4-SDRAM |
| Klokgeheugen-snelheden ondersteund door processor: | 2400 MHz |
| ECC: | Ja |
| Kloksnelheid geheugen: | 2666 MHz |
| Geheugenlayout: | 1 x 8 GB |
| Geheugenslots: | 4 |
| Aantal displays ondersteund (door on-board grafische adapter): | 3 |
| Ethernet interface type: | Gigabit Ethernet |
| Aantal geïnstalleerde processoren: | 1 |
| Geheugenbandbreedte ondersteund door de processor ( max): | 37.5 GB/s |
| Schaalbaarheid: | 1S |
| Thermal solution specificatie: | PCG 2015C |
| Geheugenkanalen ondersteund door processor: | Dual |
| HDD omvang: | - " |
| Maximum aantal HDD's per behuizing: | 2 |
| Maximale opslagcapaciteit: | - TB |
| Ondersteunde HDD-groottes: | 3.5 " |
| Hot-plug ondersteuning: | Nee |
