The HP ProLiant DL360 G7 combines performance, intelligent power and cooling management with IT management tools and
essential fault tolerance, all optimized for space constrained installations. A 1U server with the improved performance of the latest
Intel 5600 series processors, Unique HP Thermal Logic Technologies that provide leadership in energy efficiencies and ProLiant iLO
3 remote management. HP continues to provide more performance, flexibility and efficiency for space constrained environments.
Front View:Front View:Front View:Front View:
Rear View:Rear View:Rear View:Rear View:
1.
Hood Cover
1.
PCI Express expansion slot 1, low profile
2.
Up to two Intel processors
2.
PCI Express expansion slot 2 full-height full-length x16 (16,
8, 4, 2, 1), 75W +EXT 75W (option for PCI-X card only
support)
3.
Video connector
3.
Power supply bay 1 (populated)
4.
Slide-out System Insight Display (SID)
4.
Power supply bay 2
5.
Removable fan modules for easy serviceability
5.
iLO 3 NIC connector
6.
Eighteen DIMM slots: DDR3 Registered (RDIMM) or
Unbuffered (UDIMM) memory
6.
Serial connector
7.
Video connector
7.
Redundant Hot Plug Power Supplies (upgradeable option)
8.
NIC 4 connector
8.
2 PCI-E Slots
9.
NIC 3 connector
10.
NIC 2 connector
11.
NIC 1 connector
12.
USB connector
13.
USB connector
What's NewWhat's NewWhat's NewWhat's New
Support for new HP hard drives, UPS
QuickSpecs
HP ProLiant DL360 Generation 7 (G7)HP ProLiant DL360 Generation 7 (G7)HP ProLiant DL360 Generation 7 (G7HP ProLiant DL360 Generation 7 (G7)
Overview
DA - 13598 North America — Version 40 — October 10, 2011
Page 1
Probleemoplossing HP ProLiant DL380G7
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Breedte: | 426.2 mm |
| Diepte: | 692.2 mm |
| Hoogte: | 43.2 mm |
| Stroomvoorziening: | AC 100 - 240V |
| Frequentie van processor: | 2.53 GHz |
| Processorfamilie: | Intel® Xeon® 5000 reeks |
| Processormodel: | E5630 |
| Aantal processorkernen: | 4 |
| Grafische adapter: | ES1000 |
| Inclusief besturingssysteem: | Windows Small Business Server |
| Ethernet LAN: | Ja |
| Processor lithografie: | 32 nm |
| Aantal USB 2.0-poorten: | 4 |
| Aantal Ethernet LAN (RJ-45)-poorten: | 5 |
| Netvoeding: | 460 W |
| Intern geheugen: | 6 GB |
| Intern geheugentype: | DDR3-SDRAM |
| Temperatuur bij opslag: | -30 - 60 °C |
| Intel® Wireless Display (Intel® WiDi): | Nee |
| Processor socket: | Socket B (LGA 1366) |
| Stepping: | B1 |
| Systeembus: | 5.86 GT/s |
| Processor aantal threads: | 8 |
| PCI Express slots versie: | 2.0 |
| Processor operating modes: | 64-bit |
| Processor cache: | 12 MB |
| Bus type: | QPI |
| Thermal Design Power (TDP): | 80 W |
| Codenaam processor: | Westmere EP |
| Processor cache type: | Smart Cache |
| ECC ondersteund door processor: | Ja |
| Processorfabrikant: | Intel |
| Maximum intern geheugen: | 384 GB |
| Totale opslagcapaciteit: | - GB |
| Soort optische drive: | DVD-ROM |
| Ondersteunde instructie sets: | SSE4.2 |
| Intel® My WiFi Technology (Intel® MWT): | Nee |
| Intel® Hyper Threading Technology (Intel® HT Technology): | Ja |
| Intel® Turbo Boost Technology: | 1.0 |
| Intel® Quick Sync Video Technology: | Nee |
| Intel® InTru™ 3D Technology: | Nee |
| Intel® Clear Video HD Technology (Intel® CVT HD): | Nee |
| Intel® Insider™: | Nee |
| Intel® Flex Memory Access: | Nee |
| Intel® AES New Instructions (Intel® AES-NI): | Ja |
| Enhanced Intel SpeedStep Technology: | Ja |
| Execute Disable Bit: | Ja |
| Idle States: | Ja |
| Thermal Monitoring Technologies: | Nee |
| CPU configuratie (max): | 2 |
| Intel® Enhanced Halt State: | Ja |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel® CVT for MID): | Nee |
| Intel® VT-x with Extended Page Tables (EPT): | Ja |
| Ingebouwde opties beschikbaar: | Nee |
| Intel® 64: | Ja |
| Intel® Virtualization Technology for Directed I/O (VT-d): | Ja |
| Intel® Clear Video-technologie: | Nee |
| Intel® Virtualization Technology (VT-x): | Ja |
| Verpakkingsgrootte processor: | 42.5 X 45 mm |
| Conflictvrije processor: | Nee |
| ARK ID processor: | 47924 |
| Intel® Trusted Execution Technology: | Ja |
| Compatibele besturingssystemen: | Windows 7/Vista/XP/2008/2008 R2/Server 2008/Server 2003, LINUX Server 10/11, VMware ESX 4.0/3.5.0 |
| Intel® Anti-Theft Technology (Intel® AT): | Nee |
| Netwerkfuncties: | Gigabit Ethernet |
| Maximale turbofrequentie van processor: | 2.8 GHz |
| Processorcode: | SLBVB |
| Type behuizing: | Rack (1U) |
| Maximaal intern geheugen ondersteund door processor: | 288 GB |
| Geheugentypen ondersteund door processor: | DDR3-SDRAM |
| Klokgeheugen-snelheden ondersteund door processor: | 800,1066 MHz |
| Kloksnelheid geheugen: | 1333 MHz |
| Geheugenslots: | 18x DIMM |
| Bedrijfstemperatuur, bereik: | 50 - 95 °F |
| Aantal geïnstalleerde processoren: | 1 |
| Geheugenbandbreedte ondersteund door de processor ( max): | 25.6 GB/s |
| Chipset moederbord: | Intel® 5520 |
| Hoogte, in bedrijf: | 0 - 3050 m |
| HDD interface: | Serial ATA, Serial Attached SCSI (SAS) |
| CPU multiplier (bus/core ratio): | 19 |
| FSB Parity: | Nee |
| Front-side bus processor: | - MHz |
| Tcase: | 77.6 °C |
| Intel® Demand Based Switching: | Ja |
| Physical Address Extension (PAE): | 40 Bit |
| Geheugenkanalen ondersteund door processor: | Trippel |
| PCI Express x16 slots: | 2 |
| Processorserie: | Intel Xeon 5600 Series |
| Grafische adapter-familie: | ATI |
| Intel® Dual Display Capable Technology: | Nee |
| Intel® FDI Technology: | Nee |
| Intel® Rapid Storage Technology: | Nee |
| Intel® Fast Memory Access: | Nee |
| RAID support: | Ja |
| HDD omvang: | - " |
| Maximum aantal HDD's per behuizing: | 8 |
| Maximale opslagcapaciteit: | 7.2 TB |
| Seriële poort(en): | 1 |
| PCI Express x8 slots: | 1 |
| aantal QPI links: | 2 |
| Soorten RAID: | 0, 1 |
| Maximum geheugen grafische adapter: | 32 MB |
| Bedrijfstemperatuur (T-T): | 10 - 35 °C |
| Relatieve vochtigheid in bedrijf (V-V): | 10 - 90 procent |
| Ingangsfrequentie voeding: | 50 - 60 Hz |
| PCI-X slots: | 1 |
