MAIN FEAMAIN FEATURESTURES
Product group Hood
Colour body Black
Material body Stainless steel
Colour chimney N/A
Material chimney -
Typology Built-in/Built-under
Installation type Free-standing
Type of control Mechanical
Type of control settings -
Decor panel options -
Motor location Integrated motor in
hood body
Operating Mode Convertible
Electrical connection rating (W) 171
Current (A) 0,75
Voltage (V) 220-240
Frequency (Hz) 50/60
Length of Electrical Supply Cord (cm) 150
Plug type Europlug
Chimney height (mm) 0-0
Height of product, without chimney (mm) 0
Height of the product 132
Width of the product 599
Depth of the product 510
Minimum niche height 0
Minimum niche width 0
Niche depth 0
Net weight (kg) 5.5
TECHNICTECHNICAL FEAAL FEATURESTURES
Type of manual control devices Slider
Type of automatic control devices -
Number of motors 1
Total power of the motors (W) 115
Number of speed settings: boost option availability 3
Boost presence No
Maximum output air extraction (m³/h) 208
Boost position air extraction (m³/h) 0
Maximum output recirculating air (m³/h) 65
Boost position output recirculating (m³/h) 0
Light Control Type On/O
Number of lights 2
Type of lamps used Halogen
Total power of the lamps (W) 56
Diameter of air outlet (mm) 125
No-return airflow flap No
Grease filter material Not washable
synthetic
Odour filter No
PERFORMANCESPERFORMANCES
Sound power at min. speed (2010/30/EU) 48
Sound power at max. speed (2010/30/EU) 67
Noise level with boost position (dB(A) re 1 pW) 0
ISLK 66 AS K
12NC F103830:
GTIN (EAN) code 8050147038307:
