Pagina 1/4
If the door is opened during the cycle, to restart it, close the door and
press the button START/PAUSE. This programme does not allow to set
other options.
OPENING OF THE DOOR DURING THE CYCLE
During operation, it is possible to open the door. After having closed it,
press the button Start/Pause again to restart the dryer.
PROGRAMMES
Eco cotton kg Max*
Standard cotton programme, suitable to dry normally wet
cotton laundry. Most ecient programme in terms of energy
consumption for drying cotton laundry. The values on the Energy
Label are based on this programme.
Synthetics kg 4
For drying laundry made of synthetic bres.
Mixed kg 4
This programme is ideal for drying cotton and synthetic fabrics
together.
Mini synthetics kg 2
Eco-drying of small laundry loads.
Mini cotton kg 2
Eco-drying of small laundry loads.
Delicates kg 2
For drying delicate laundry requiring a gentle treatment.
Wool kg 1
Programme for drying wool clothing. It is advisable to turn the
garments inside out before drying. Leave to dry naturally the heaviest
edges that are still damp.
FIRST TIME USE
Make sure that the water tank is correctly inserted. Make sure
that the drain hose on the back of the dyrer is properly xed,
either to the dryers's water tank or to the domestic sewage
system.
The dryer must be installed in a room with a temperature
ranging between 5°C and 35°C to ensure proper operation.
Before you use your dryer ensure that it has been in a upright
position for at least 6 hours.
DAILY USE
Doing this will keep your machine working at its BEST!
Remember to empty your water tank after each drying cycle.
Remember to clean your lters after each drying cycle. (Refer to
section Care & Maintanence).
1. Open the door and load garments. Always refer to instructions
on clothing labels and the max loads indicated in the programme
section. Empty pockets. Make sure garments do not get caught
between the door and/or the door lter.
2. Close the door.
3. Press the button On/O .
4. Select the programme according to the laundry type.
5. Select the options, if necessary.
6. To start the cycle, press the Start/Pause button.
7. At the end of the drying cycle, a buzzer will beep. An indicator on
the control panel signals the end of the cycle. Pull the load out
immediately to prevent the formation of creases on laundry.
8. Turn the machine o by pressing the button On/O, open the
door and pull clothing out. If the machine is not switched o
manually, after about a quarter of an hour from the cycle end, the
appliance turns o automatically to save energy.
If this last stage is not carried out immediately, some machines
and/or some programmes/options are equipped with Crease Care
system. For some hours, after the end of drying, the drum rotates at
regular intervals to prevent the formation of creases.
In case of power failure, it is necessary to press the button Start/
Pause to restart the cycle.
PUSH & GO
This function serves to start a cycle, after machine switching on,
without enabling any further button an/or knob (the programme
PUSH & GO will be deactivated instead).
It is always necessary to follow the points 1, 2, and 3
concerning the daily use.
To start the cycle Touch & GO, keep the button pressed. The light
on signals that the cycle is started. The cycle is suitable for cotton
and synthetic textiles. Max. load 4 kg. (Cycle duration 131’).
*MAX LOAD 8 Kg (Dry load)
CARE LABEL
Always check the care labels, especially when placing garments in
the tumble dryer for the rst time. Below are the most commonly
used symbols:
May be tumble dried.
Do not tumble dry.
Tumble dry – high heat.
Tumble dry – low heat.
THANK YOU FOR BUYING A INDESIT PRODUCT.
In order to receive a more complete assistance,
please register your product on
www.indesit.eu/register
EN
Quick guide
Before using the appliance carefully read the Safety Instructions.
CONTROL PANEL
1 ON/OFF button (Reset if long pressed)
2 Programme selection knob
3 Start/Pause
4 Push & Go
Options buttons*
5 Dryness level
6 Start delay
7 Timed drying
8 Cycle end
9 Light drying (Key lock if long pressed)
10 Crease care (Mute if long pressed)
*Note: some models may have the wording in full instead of the icons
INDICATORS
Dryness level: Iron dry - Hanger dry - Cupboard dry - Extra dry -
Cycle phase: END - Dry - Cool tumble - End of cycle
Empty water tank Clean door lter Clean bottom lter
Refer to Troubleshooting section: Failure: Call after sales service -
DEMO
Demo mode
1
3
2
4
10
8
9
5 6 7
DEMO
3’’
3’’
Probleemoplossing Indesit YT M11 82 X UK
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Apparaatplaatsing: | Vrijstaand |
| Soort bediening: | Buttons,Rotary |
| Kleur van het product: | Wit |
| Deurscharnieren: | Rechts |
| Ingebouwd display: | Ja |
| Warmtebron: | Electrisch |
| Gewicht: | 44000 g |
| Breedte: | 595 mm |
| Diepte: | 649 mm |
| Hoogte: | 849 mm |
| Netbelasting: | 850 W |
| Type lader: | Voorbelading |
| Droogsysteem: | Condensatie |
| Deurkleur: | Wit |
| Snoerlengte: | 1.5 m |
| Trommelinhoud: | 120 l |
| Uitgestelde start timer: | Ja |
| Startvertraging: | 24 uur |
| Resterende tijd indicatie: | Ja |
| Kinderslot: | Nee |
| Aantal droogprogramma's: | 15 |
| Droogklasse: | B |
| Duur cyclus: | 194 min |
| Geluidsniveau: | 65 dB |
| Anti-kreuk functie: | Nee |
| Vochtsensor: | Ja |
| Energie-efficiëntieklasse: | A++ |
| Energie consumptie: | 1.78 kWu |
| Jaarlijks energieverbruik: | 234 kWu |
| Gewicht verpakking: | 47000 g |
| Breedte verpakking: | 655 mm |
| Diepte verpakking: | 675 mm |
| Hoogte verpakking: | 872 mm |
| Tijdsduur tot uitschakelen: | 15 min |
| Diepte wanneer de deur open is: | 1095 mm |
| Stroomverbruik (indien uit): | 0.5 W |
| Huidige waardering: | 10 A |
| Nominale capaciteit: | 8 kg |
| AC-ingangsspanning: | 220 - 240 V |
| AC-ingangsfrequentie: | 50 Hz |
| Type beeldscherm: | LED |
| Energie-efficiëntieschaal: | A+++ tot D |
| Indicator watertank vol: | Ja |
| Droogprogramma's: | Wool,Cotton,Synthetics |
