Compact enclosure
258 mm (10 in) LF transducer
90° x 50° Progressive Transition™ Field
Rotatable Waveguide with a 25 mm (1 in) exit
35mm (1.5 ) voice-coil compression driver"
Dual Neutrik NL4 connectors plus screw
terminals
Multiple attachment points for ultimate
exibility
Specications:
Applications:
Performing Spaces
Clubs & Bars
Houses of Worship
Multi Media Spaces
Retail & Hospitality Spaces
Presentation Suites
Educational Facilities
AC195 is a compact 2-way full-range loudspeaker
system comprised of one 258 mm (10 in) low
frequency driver and one 25 mm (1 in) exit/35 mm
(1.5 in) voice-coil compression driver. e rotatable
PT™ Progressive Transition waveguide provides 90°
by 50° coverage in vertical cabinet orientation. High-
slope passive crossovers minimize band overlap and
well-controlled oaxis response.
e cabinet is tted with M10 threaded suspension
points. Four threaded inserts located on back of the
enclosure allow attachment of a MultiMount® or
similar type mounting.
AC195 is part of JBL’s AE Application Engineered
Series, a versatil e family of loudspeakers for a wide
variety of xed installation applications.
Key Features:
AC195 2-Way Full-Range Loudspeaker
with 1 x 10 LF"
System:
Frequency Range (-10 dB)1: 68 Hz - 20 kHz
Frequency Response ( 3 dB)±1: 85 Hz - 18kHz
System Sensitivity (1w @ 1m)1: 95 dB
Nominal Impedance: 8 ohms
Maximum SPL(1m)2: 118 dB (124 dB peak)
300W (1200W peak), 2 hrs3: 200 W/400 W/800 W
(Continuous/Program/Peak)
2 hr Power Rating4:
System Power Rating (AES): 300W (1200W peak), 2 hrs
Coverage Pattern: 90° x 50° (H x V)
Crossover: 1.8 kHz
Transducers:
Low frequency driver: 1 x 10 woofer (P/N: 5050692), 258 mm (10 in) "
driver with 66 mm (2.5 in) voice-coil
High frequency driver: 1 x 2408H-2 driver with 25 mm (1 in) exit/35 mm (1.5
in) voice-coil
Physical:
Input Connector: Dual Neutrik NL4MP connectors plus covered bar-
rier trip terminals
Enclosure: 15 mm multi-ply hardwood plywood
Grille: Powder coated, 1.5mm perforated steel, with acous-
tically transparent black foam backing
Finish: Textured black paint nish. White (-WH) available
upon request. Not available with WRC & WRX
nish.
Suspension / Mounting: 14 x M10 and 4 x M10 for Wall Mount Bracket.
Optional U-bracket, overhead suspension bracket, and
wall-mount bracket
Dimensions (H x W x D): 535 mm x 310 mm x 329 mm
21.0 in x 12.2 in x 12.9 in
Net Weight: 13.1 kg (28.8 lbs)
JBL continually engages in research related to product improvement. Some
materials, production methods and design renements are introduced into
existing products without notice as a routine expression of that philosophy.
For this reason, any current JBL product may dier in some respect from
its published description, but will always equal or exceed the original
design specications unless otherwise stated.
1 Full space (4π) conditions
2 Calculated maximum SPL based on rated power handling
3. IEC shaped pink noise with 6dB CF for 100hrs
4 AES standard, one decade pink noise with 6 dB crest factor within device’s operational band, free air. Standard AES 2 hr rating
plus long-term 100 hr rating are specied for low-frequency transducers.
