L82 Classic MkII
2-Way 8-inch (200mm) Bookshelf Loudspeaker
Quick Start Guide
jbl.com/specialty-audio/
Overview
For more information on the set-up and operation of this
product refer to the product page on the jbl.com/specialty-audio/
website. Should further assistance be required feel free to
contact customer support at the numbers below.
Inside the US and Canada: +1 888.691.4171
Outside the US and Canada: +44 1707 668 012
Box Contents
2x L82 Classic MkII Edition Loudspeakers
2x Quadrex Foam Grilles
1x Quick Start Guide (This Document)
Placement and Positioning
●
Before deciding where to place your speakers, survey your room and think
about placement, using the illustration as a guide.
●
Avoid placing the speakers near power amplifiers, heat registers or other objects
that generate large amounts of heat.
●
Avoid placing speakers in humid or dusty locations.
●
Avoid placing speakers in direct sunlight or other intense light.
●
Refer to the illustration for distances from walls, between the speakers, and
angle to the listening position.
●
The speakers should be raised so that the tweeter is approximately at ear level.
The JS-80 speaker stand (sold separately) can be used to achieve the proper
listening height.
●
Angle the speakers towards the listening position closer to the listeners ears for
a stronger center image and away from the listening position further from the
listeners ears for a more spacious image.
Specifications
Type: 8-inch (200mm) 2-way Bookshelf Loudspeaker
Low Frequency Driver:
8in (200mm) cast-frame Pure Pulp cone woofer (JW200PW2-6)
High Frequency Driver: 1in (25mm) Titanium dome tweeter with waveguide (JT025Ti2-4)
Recommended
Amplifier Power:
25 ~ 150W RMS
Impedance: 8 Ohms
Loudspeaker Sensitivity: 88dB (2.83V/1m)
Frequency Response: 44Hz ~ 40kHz (-6 dB)
Crossover Frequency: 1.7kHz
Finish:
Natural Walnut veneer with Black, Orange, or Blue Quadrex
Foam Grille
Dimensions With Grille:
(HxWxD)
18.6-inch x 11.0-inch x 12.4-inch (472.7mm x 280.2mm x
315.0mm)
Controls: HF level control
Input Type: Dual sets of Gold-plated Binding Posts
Product Weight (Each):
28lbs (12.8kg)
Shipping Weight: 70lbs (31.8kg)
Shipping Units of Measure:
Stereo Pair (Mirrored Left/Right)
Recommended Stand Height: 16in (404mm)
Recommended Stand: JBL JS-80 (Sold Separately)
JBL L82 Classic MkII Quick Start Guide | Rev3.0 20230501 | Part No. 950-0622-001
©2023 Harman International | Features, Specifications, and Appearance subject to change without notice.
Pg 1 of 2
20in
(51cm)
20in
(51cm)
6ft (1.8mm) to
8ft (2.4mm)
Angle speaker to suit
listening preference.
See Postioning Bullet
Listening Position
40° to 60°
