SCS500.5 SYSTEM
Frequency Response
30Hz – 20kHz (–6dB)
SATELLITES
Maximum Recommended Amplifier Power
100 Watts
Nominal Impedance 8 Ohms
Sensitivity 88dB @ 1 Watt/1 meter
Frequency Response 100Hz – 20kHz (–6dB)
Tweeter
1/2" (13mm) Titanium-laminate dome,
video-shielded
Midrange
Dual 3" (75mm) drivers, video-shielded
Dimensions (H x W x D)
(not including shelf stand)
11-1/2" x 4" x 3-1/2" (292mm x 102mm x 89mm)
Weight 3 lb (1.4kg)
CENTER
Maximum Recommended Amplifier Power
100 Watts
Nominal Impedance 8 Ohms
Sensitivity 88dB @ 1 Watt/1 meter
Frequency Response 100Hz – 20kHz (–6dB)
Tweeter
1/2" (13mm) Titanium-laminate dome,
video-shielded
Midrange
Dual 3" (75mm) drivers, video-shielded
Dimensions (H x W x D)
(not including shelf stand)
4" x 11-1/2" x 3-1/2" (102mm x 292mm x 89mm)
Weight 3 lb (1.4kg)
SUBWOOFER
Amplifier 150 Watts RMS
Frequency Response 30Hz – 120Hz (–6dB)
Woofer 10" (250mm)
Enclosure Bass-reflex
Dimensions (H x W x D)
(including feet)
20" x 13-3/4" x 15-3/4"
(508mm x 349mm x 400mm)
Weight 35 lb (15.9kg)
SPECIFICATIONS
All features and specifications are subject to change
w
ithout notice.
Dolby and Pro Logic are registered trademarks of
Dolby Laboratories.
DTS is a registered trademark of DTS, Inc.
DESIGN GOAL: Bring the thrill of live performance and movie sound
to
the home environment bycalling on JBL’s professional engineering leadership.
SATELLITE TYPE:
Titanium-laminate-dome tweeter,
sealed enclosure
SUBW OOFER
TYPE :
Bass-reflex enclosure
PORT DESIGN: FreeFlow
™
flared
PROF ESSIONAL REFE RENCE: Cinema Loudspeaker Series
OWNER’S GUIDE
P R O D U C T
L I N E :
MODEL:
SCS500.5
SURROUND CINEMA
SPEAKERS
© 2007 Harman International Industries, Incorporated.
All rights reserved.
JBL is a trademark of Harman International Industries,
Incorporated, registered in the United States and/or
other countries.
Part No.
406-000-05677-E
PRO SOUND
COMES HOME
™
Harman Consumer Group, Inc.
250 Crossways Park Drive, W
oodbury
, NY
11797
8500 Balboa Boulevard, Northridge, CA 91329
516.255.4JBL
(4525) (USA
only)
www.jbl.com
SCS500.5
