Pagina 1/8
Occasional refinements may be made to
existing products without notice but will
always meet or exceed original specifications
unless otherwise stated.
†The maximum recommended amplifier power
rating will ensure proper system headroom to
allow for occasional peaks. We do not recom-
mend sustained operation at these maximum
power levels.
* Dolby and Pro Logic are trademarks of
Dolby Laboratories.
DTS is a registered trademark of
Digital Theater Systems, Inc.
SP5
Frequency Response
45 10dB) – 20kHz (–
Recommended Maximum
Amplifier Power †
60 watts
Impedance
8 ohms nominal
Sensitivity
87dB (2.83V/1m)
Crossover Frequency
3,000Hz
Woofer
5-/1/4
" titanium-laminate cone
w/rubber surround
Tweeter
1" titanium-laminate dome,
w/Elliptical Oblate Spheroidal™
(EOS) waveguide, and swivel
mount
Plate Size (W x H)
7-1/2" x 10" (191mm x 254mm)
Mounting Cutout Size (W x H)
6-1/8" x 8-11/16" (156mm x 221mm)
Mounting Depth
3-3/4" (95mm)
SP6
Frequency Response
38 10dB) – 20kHz (–
Recommended Maximum
Amplifier Power †
80 watts
Impedance
8 ohms nominal
Sensitivity
88dB (2.83V/1m)
Crossover Frequency
2,000Hz
Woofer
6-/1/2
" titanium-laminate cone
w/rubber surround
Tweeter
1" titanium-laminate dome,
w/Elliptical Oblate Spheroidal™
(EOS) waveguide, and swivel
mount
Plate Size (W x H)
8-1/2" x 11" (216mm x 297mm)
Mounting Cutout Size (W x H)
7-1/8" x 9-11/16" (181mm x 246mm)
Mounting Depth
3-7/8" (98mm)
SP6C
Frequency Response
40 10dB) – 20kHz (–
Recommended Maximum
Amplifier Power †
80 watts
Impedance
8 ohms nominal
Sensitivity
88dB (2.83V/1m)
Crossover Frequency
3,000Hz
Woofer
6-/1/2
" titanium-laminate cone
w/rubber surround
Tweeter
1" titanium-laminate dome,
w/Elliptical Oblate Spheroidal™
(EOS) waveguide, and swivel
mount
Plate Size (Diameter)
9-3/16" (233mm)
Mounting Cutout Size (Diameter)
7-7/8" (200mm)
Mounting Depth
4-1/4" (108mm)
Declaration of Conformity
We, Harman Consumer International
2, route de Tours
72500 Chateau-du-Loir
FRANCE
declare in own responsibility, that the products described in this
owner’s manual are in compliance with technical standards:
EN 50081-1:1992
EN 50082-1:1992
Steen Michaelsen
Harman Consumer International
Chateau-du-Loir, FRANCE. 9/00
D E S I G N G O A L : Combine the superior performance of traditional
JBL loudspeakers with the convenience of in-wall installation.
TWEETER TYPE:Titanium-laminate-dome with EOS
waveguide, and swivel mount
W O O F E R T Y P E :
Titanium-laminate cone with rubber surround
C R O S S O V E R N E T W O R K : Straight-Line Signal Path (SSP)™
P R O F E S S I O N A L R E F E R E N C E : Studio Monitor
O W N E R ’S G U I D E
P R O D U C T L I N E :
M O D E L S :
SP5, SP6 and SP6C
SoundPoint
™
Series
S P E C I F I C AT I O N S
©2000 JBL, Incorporated.
JBL is a registered trademark of JBL, Incorporated.
Part No.
170-0021
P R O S O U N D
C O M E S H O M E
™
JBL Consumer Products
250 Crossways Park Drive, Woodbury, NY 11797
8500 Balboa Boulevard, Northridge, CA 91329
800-336-4JBL (4525) (USA only)
www.jbl.com
NOTE: For new-construction applications, be sure
to purchase the correct rough-in frame kit.
