Pagina 1/19
TQFP
Top View
1
2
3
4
5
6
7
8
9
10
11
33
32
31
30
29
28
27
26
25
24
23
I/O
I/O
I/O
GND
I/O
I/O
I/O
I/O
VCC
I/O
I/O
I/O
I/O
I/O
I/O
VCC
I/O
I/O
I/O
I/O
GND
I/O
44
43
42
41
40
39
38
37
36
35
34
12
13
14
15
16
17
18
19
20
21
22
I/O
I/O
I/O
I/O
GND
VCC
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O/PD
VCC
OE2/I
GCLR/I
OE1/I
CLK/I
GND
I/O
I/O
PLCC
Top View
7
8
9
10
11
12
13
14
15
16
17
39
38
37
36
35
34
33
32
31
30
29
I/O
I/O
I/O
GND
I/O
I/O
I/O
I/O
VCC
I/O
I/O
I/O
I/O
I/O
I/O
VCC
I/O
I/O
I/O
I/O
GND
I/O
6
5
4
3
2
1
44
43
42
41
40
18
19
20
21
22
23
24
25
26
27
28
I/O
I/O
I/O
I/O
GND
VCC
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O/PD
VCC
OE2/I
GCLR/I
OE1/I
CLK/I
GND
I/O
I/O
Pin Configurations
Pin
Name Function
CLK Clock
I Logic Inputs
I/O Bi-directional
Buffers
GCLR Register Reset
(active low)
OE1,
OE2
Output Enable
(active low)
VCC +5V Supply
PD Power-down
(active high)
Features
•High-density, High-performance Electrically-erasable Complex
Programmable Logic Device
– 44-pin, 32 I/O CPLD
– 7.5 ns Maximum Pin-to-pin Delay
– Registered Operation Up to 125 MHz
– Fully Connected Input and Feedback Logic Array
– Backward Compatibility with ATF1500/L Software and Hardware
•Flexible Logic Macrocell
– D/T/Latch Configurable Flip-flops
– Global and Individual Register Control Signals
– Global and Individual Output Enable
– Programmable Output Slew Rate
•Advanced Power Management Features
– Automatic 3 mA Standby (ATF1500AL)
– Pin-controlled 10 mA Standby Mode
– Programmable Pin-keeper Inputs and I/Os
•Available in Commercial and Industrial Temperature Ranges
•Available in 44-lead PLCC and TQFP Packages
•Advanced Flash Technology
– 100% Tested
– Completely Reprogrammable
– 100 Program/Erase Cycles
– 20 Year Data Retention
– 2000V ESD Protection
– 200 mA Latch-up Immunity
•Supported by Popular third-arty Tools
•Security Fuse Feature
•Pin-compatible with the Most Commonly Used Devices
•Green (Pb/Halide-fee/RoHS Compliant) Package Options
Description
The ATF1500A is a high-performance, high-density complex PLD. Built on an
advanced Flash technology, it has maximum pin-to-pin delays of 7.5 ns and supports
sequential logic operation at speeds up to 125 MHz. With 32 logic macrocells and up
to 36 inputs, it easily integrates logic from several TTL, SSI, MSI and classic PLDs.
The ATF1500A’s global input and feedback architecture simplifies logic placement
and eliminates pinout changes due to design changes.
High-
performance
EPLD
ATF1500A
ATF1500AL
Rev. 0759F–6/05
(continued)
