Supertex inc.
Supertex inc.
www.supertex.com
MD1711DB2
Doc.# DSDB-MD1711DB2
B032114
General Description
The MD1711DB2 demoboard is as a ve-level, dual-channel,
+/-100V, 2.0A, return-to-zero pulser. It can directly drive two
50 or 75Ω impedance transducers for 1.0MHz to 20MHz
medical ultrasound imaging or NDT applications.
The MD1711DB2 consists of one MD1711 in a 48-Lead LQFP
package driving six TC6320 complementary high voltage
MOSFET pairs in 8-Lead SOIC packages. The external logic
signal connector, J13, connects all the input control signals of
the MD1711 to the user’s logic control source via a short ribbon
cable. In typical two-, three- or ve-level bipolar pulsing, PW or
CW waveforms can be generated by the proper input control
signal listed below. Jumpers are provided for the output, such
that it can drive either the on-board RC load 220pF capacitor
in parallel with a 1.0KΩ resistor or with an external load of
cable to the user’s ultrasound testing transducer.
Block Diagram
MD1711 + TC6320 Demoboard
Five-Level, Dual Channel ±100V 2.0A RTZ Pulser
Features
►Five-level, dual-channel ultrasound transmitter
►MD1711 driving six TC6320 HV MOSFETs
►Design for RTZ waveforms outputs
►Low second harmonic distortion
►Dual 0 to +/-100V peak to peak voltage supply
►±2.0 A source and sink current capability
►SMA connectors for external clock and signals
►1.8 to 3.3V CMOS logic interface
Applications
►Medical ultrasound imaging
►Ultrasonic NDT inspection
►Piezoelectric transducer drivers
►ATE and waveform generator
►PZT transducer drivers
►Capacitive and MEMS sensor driver
10nF
DV
DD
1
1.0µF
-50V
Supertex
TC6320
V
LL
SEL
EN
AV
SS
DV
SS
AGND
DGND
POSA / POS1A
CLAMPA
NEGA / NEG1A
HVEN1A / POS2A
HVEN2A / NEG2A
POSB / POS1B
CLAMPB
NEGB / NEG1B
HVEN1B/ POS2B
HVEN2B / NEG2B
V
SS
DV
DD
1
V
SS
DV
DD
1
Supertex
MD1711
XDCR-A
Control
Logic
and
Level
Translate
DV
DD
2
AV
DD
1
XDCR-A
1.0µF
1.0µF
1.0µF
1.0µF
1.0µF
1.0µF
1.0µF
+50V
-100V
+100V
-50V
+50V
-100V
+100V
10nF
10nF
10nF
10nF
10nF
10nF
10nF
DV
DD
1
DV
DD
1
DV
DD
2
DV
DD
2
DV
DD
2
DV
DD
2
DV
DD
1
DV
DD
1
