2016-2021 Microchip Technology Inc. DS80000704J-page 1
MEC170x
TABLE 1: SILICON IDENTIFICATION
Part
Number Silicon Identifier Functional
Revision C
Functional
Revision E
Functional
Revision F
MEC1701 Device ID(1) 2Dh 2Dh 2Dh
Revision ID for Silicon Revision( )282h 84h 85h
PIS(3) Version/Revision C1 C2 C2
MEC1703 Device ID(1) 2Eh 2Eh 2Eh
Revision ID for Silicon Revision( )282h 84h 85h
PIS(3) Version/Revision F1 F2 F2
MEC1704 Device ID(1) 33h 33h 33h
Revision ID for Silicon Revision( )282h 84h 85h
PIS(3) Version/Revision C1 C2 C2
MEC1705 Device ID(1) 32h 32h 32h
Revision ID for Silicon Revision( )282h 84h 85h
PIS(3) Version/Revision C1 C2 C2
Note 1: The Device ID is visible as an 8-bit number at Plug and Play Configuration Index 20h.
2: The HW Revision Number is visible as an 8-bit number at Plug and Play Configuration Index 21h.
3: Product Identification System (PIS) is defined in the Product Data Sheet.
TABLE 2: SILICON ISSUE SUMMARY
Module Feature Item
Number Issue Summary
Affected Revisions(1)
C E F
SMB Controller SMB Master 1. SMBus Master Controller violates Bus Idle
Time between STO and STA in Byte mode
only
XXX
Boot ROM Crisis Recov-
ery
2. May enter crisis recovery mode in error X X X
JTAG Pins Pins 3. GPIO145 & GPIO146 input disabled in
SWD mode
XXX
EEPROM Con-
troller
TEST 4. For MEC1703 and MEC1705, Test
Register at address 0x4000_2C1C
needs to be programmed to
0x00060101
XXX
ESPI ESPI 5. MAFS flash transfers should be to/from 4-
byte aligned SRAM buffer starting
addresses
XXX
Note 1: Only those issues indicated in the last column apply to the current silicon revision.
2: Please refer to the description below to know a list of parts that are affected.
MEC170x
Silicon Errata and Data Sheet Clarification
